CHAPTER 1: BEFORE YOU START
D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 33
RoHS compliance
The Environmental protection use period (EPUP), as defined in PRC SJ/T11364-2014 for
D20E product as listed in
Table 3, can be recycled, and does not contain any hazardous
substances and must be recycled.
The following hazardous substances are covered:
•Pb: Lead
•Hg: Mercury
Cd: Cadmium
Cr6: Hexavalent Chromium
PBB: Polybrominated biphenyls
PBDE: Polybrominated diphenyl ethers
Table 3: RoHS Material Declaration Data Content by Assembly
GE part
number
Description Pb Hg Cd Cr6 PBB PBDE
507-0501LF D20E-S - Status Input Logic Main O O O O O O
508-0501LF D20E-K - Control Logic Main O O O O O O
509-0501LF D20E-C - Combination Logic Main O O O O O O
511-0501LF D20E-A - DC Analog Logic Main O O O O O O
517-0501LF D20E-A - CTB 5VDC AI LVPSU Interface O O O O O O
517-0502LF D20E-A - DTB 5VDC AI LVPSU Interface O O O O O O
517-0503LF D20E-K - CTB T/C LVPSU Interface O O O O O O
517-0504LF D20E-K - DTB T/C LVPSU Interface O O O O O O
517-0505LF D20E-K - DB25 T/C LVPSU Interface O O O O O O
517-0506LF D20E-S - Standard Compression, 20 to 60
VDC LVDI, 20 to 60 VDC, 2X10/100 Base-T
O O O O O O
517-0507LF D20E-S - Standard Compression, 90 to 290
VDC HVDI, 20 to 60 VDC, 2X10/100 Base-T
O O O O O O
517-0508LF D20E-S - Compression disconnect, 20 to 60
VDC LVDI, 20 to 60 VDC, 2X10/100 Base-T
O O O O O O
517-0509LF D20E-S - Compression disconnect, 90 to 290
VDC HVDI, 20 to 60 VDC, 2X10/100 Base-T
O O O O O O
517-0510LF D20E-C - Standard Compression, Trip/Close, 5
V Analog Input, 20 to 60 VDC LVDI, 20 to 60
VDC, 2x10/100 Base-T
O O O O O O
517-0511LF D20E-C - Standard Compression, Trip/Close,
5V Analog Input, 90-290VDC HVDI, 20 to 60
VDC, 2x10/100 Base-T
O O O O O O
517-0512LF D20E-C - Compression disconnect, Trip/Close,
5 V Analog Input, 20 to 60 VDC LVDI, 20 to 60
VDC, 2x10/100 Base-T
O O O O O O
517-0513LF D20E-C - Standard Compression, Trip/Close,
5V Analog Input, 90 to 290 VDC HVDI, 20 to 60
VDC, 2x10/100 Base-T
O O O O O O
517-0514LF D20E-A - Standard Compression, 20 mA
Analog Input, 20 to 60 VDC, 2x 10/100 Base-T
O O O O O O
517-0515LF D20E-C - Standard Compression, Trip/Close,
20 mA Analog Input, 20 to 60 VDC LVDI, 20 to
60 VDC, 2x10/100 Base-T
O O O O O O
517-0516LF D20E-C - Compression disconnect, Trip/Close,
20mA Analog Input, 20 to 60 VDC LVDI, 20 to
60 VDC, 2x10/100 Base-T
O O O O O O
