GE Multilin D20E User Manual

76 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
CHAPTER 4: MOUNTING A D20E MODULE
Rack mounting procedure
To mount the D20E module in a rack:
1. Determine the location of the D20E module in a 19-inch mounting rack.
2. Install, but do not tighten the top two mounting screws.
NOTE
Install the D20E module with the LEDs visible from the front of the rack.
3. Slide the D20E module over the top mounting screws and drop down into position.
4. Insert the bottom mounting screws.
5. Tighten all four mounting screws.
You are now ready to connect ground, power, and network link cabling to the D20E
module:
See chapter: Mounting a D20E Module on page 75.
See chapter: Connecting Field Wiring to the D20E Module on page 87
