CHAPTER 7: CONNECTING FIELD WIRING TO THE D20E MODULE
D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 97
D20E-C combination inputs and outputs module
Termination block TB2 is a two-tier terminal block. See Table 26 for the terminal block
assignments.
The wiring connected to terminal block TB2 must not have exposed accessible
conductors.
The wire and cable connected must have at least a +80 °C temperature rating.
Table 26: D20E-C - combination input/output module terminal block assignment
TB2 Descriptions TB2 Descriptions
1 External Digital Input/Control Output
(DPST) DC Supply +/‒
51 External Digital Input/Control Output DC
Supply ‒/+
2 External Control Output (T/C and R/L) DC
Supply +/‒
52 Trip 1/Raise 4/ Normal Open 1/DO1+
3 Close 1/Common 1/DO1‒ 53 Normal Close 1
4 Trip 2/Lower 4/ Normal Open 2/DO2+ 54 Close 2/Common 2/DO2‒
5 Normal Close 2 55 Trip 3/Raise 3/ Normal Open 3/DO3+
6 Close 3/Common 3/DO3 56 Normal Close 3
7 Trip 4/Lower 3/Normal Open 4/DO4+ 57 Close 4/Common 4/DO4‒
8 Normal Close 4 58 Trip 5/Raise 2/ Normal Open 5/DO5+
9 Close 5/Common 5/DO5‒ 59 Normal Close 5
10 Trip 6/Lower 2/Normal Open 6/DO6+ 60 Close 6/Common 6/DO6‒
11 Normal Close 6 61 Trip 7/Raise 1/ Normal Open 7/DO7+
12 Close 7/Common 7/DO7‒ 62 Normal Close 7
13 Trip 8/Lower 1/Normal Open 8/DO8+ 63 Close 8/Common 8/DO8‒
14 Normal Close 8 64 Analog 1+
15 Analog 1‒ 65 Shield/Screen Ground
16 Analog 2+ 66 Analog 2‒
17 Analog 3+ 67 Analog 3‒
18 Shield/Screen Ground 68 Analog 4+
19 Analog 4- 69 Analog 5+
20 Analog 5‒ 70 Shield/Screen Ground
21 Analog 6+ 71 Analog 6‒
22 Analog 7+ 72 Analog 7‒
23 Shield/Screen Ground 73 Analog 8+
24 Analog Input 8‒ 74 Analog 9+
25 Analog 9‒ 75 Shield/Screen Ground
26 Analog 10+ 76 Analog 10‒
27 Analog 11+ 77 Analog 11‒
28 Shield/Screen Ground 78 Analog 12+
29 Analog 12‒ 79 Analog 13+
30 Analog 13‒ 80 Shield/Screen Ground
31 Analog 14+ 81 Analog 14‒
32 Analog 15+ 82 Analog 15‒
33 Shield/Screen Ground 83 Analog 16‒
34 Analog 16+ 84 Status Wetting 1to 16
35 Status Input 1 85 Status Wetting 1to 16
