48 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
CHAPTER 3: CONFIGURING THE D20E FIRMWARE
Import an existing project from a device
The DAPserver Studio version should match the firmware on the D20E module. If the D20E
is running a firmware version that is older than the DAPserver Studio software version,
DAPserver Studio may not connect (communicate) with the older D20E firmware device.
However, most older firmware versions on the D20E will connect to the latest DAPserver
Studio.
To import an existing project file from a device:
1. Open DAPserver Studio.
2. Click the From Device box.
3. Result: The Project page appears.
4. Type in the project Name and Description.
5. Select an empty Folder to store the project configuration.
6. Type in the IP Address of the D20E (DAP IO).
7. Type in the Username and Password.
8. Click OK.
Save a project
To save a project configuration after modifications have been made:
1. Open the Settings menu bar.
2. Click Save.
