44 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
CHAPTER 3: CONFIGURING THE D20E FIRMWARE
Create a project
To create a project:
1. Open DAPserver Studio.
2. Click the New > Blank box on the main pane.
Result: The Device window appears.
A D20E project must be created from a blank template.
If your D20E is to be connected to a GE Grid Solutions D20, D20MX, D400, or DMC490
device, only use the device template files provided on the D20E Doc CD. Do not use
the device template files available on DAPserver Studio.
3. Type in the Project Name and Description.
4. Click the … (browse) button to the right of the Folder field. Create the folder that is to
store the new project configuration.
Each project must be stored in a unique folder which can be created from this screen.
The Main Project Folder created at the beginning of this guide is intended to hold each
of these folders, but is not required.
