32 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
CHAPTER 1: BEFORE YOU START
Testing and certification
Approvals
Tests and Standards
Approval Applicable council directive … According to …
CE compliance Low voltage directive EN 61010-1, EN 61010-2-030
EMC Directive EN61326-1
ISO Manufactured under a registered
quality program
ISO9001
Test Reference Standard Test Level
Dielectric voltage withstand EN60255-5/IEC 60255-27 2.8 kV
Impulse voltage withstand EN60255-5/IEC 60255-27 5 kV
Insulation resistance IEC 60255-5/IEC 60255-27 500 VDC (test level)
Damped Oscillatory IEC 60255-22-1 2.5 kV CM, 1 kV DM, 1 MHz
Electrostatic Discharge EN61000-4-2/IEC 60255-22-2 Level 4
RF immunity EN61000-4-3/IEC 60255-22-3 Level 3
Fast Transient Disturbance EN61000-4-4/IEC 60255-22-4 Level 4
Surge Immunity EN61000-4-5/IEC 60255-22-5 Level 3
Conducted RF Immunity EN61000-4-6/IEC V 60255-22-6 Level 3
Power Frequency Immunity IEC 61000-4-16 Level 4
Voltage interruption and Ripple
DC
IEC 60255-11 PQT levels based on
IEC 61000-4-29, and
IEC 61000-4-17
Radiated and Conducted
Emissions
CISPR11 /CISPR22/ IEC 60255-25 Class A
Sinusoidal Vibration IEC 60255-21-1 Class 1
Power magnetic Immunity IEC 61000-4-8 Level 5
Conducted RF Immunity 0 to
150 kHz
IEC 61000-4-16 Level 4
b
Ingress Protection IEC 60529 IP30 front
Environmental (Cold) IEC 60068-2-1 -40 °C
Environmental (Dry heat) IEC 60068-2-2 +85 °C
Relative Humidity (Steady State) IEC 60068-2-78 95% RH, +40 °C
EFT IEEE/ANSI C37.90.1 4 kV, 5 kHz
Damped Oscillatory IEEE/ANSI C37.90.1 2.5 kV, 1 MHz
Make and Carry IEEE C37.90 4 A
Electrostatic Discharge (ESD) IEEE/ANSIC 37.90.3 8 kV CD/ 15 kV AD
Product Safety IEC 61010-1 As per Normative sections
