CHAPTER 1: BEFORE YOU START
D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 31
Communication ports
LAN Ports Two 10/100Base-T LAN ports with unique MAC and IP address, each port
has a switched connection (four RJ45)
Protocol DNP3 TCP/IP with subset level 2 or IEC 61850 GGIO
Time Synchronization NTP or DNP3
Time Mode UTC or Local time
Local Indications Link (green) and Activity (yellow) LEDs per RJ45 connector
LAN Conducted
Immunity
As per:
• IEEE C37.90.1
• IEC 61000-4-4
• IEC 61000-4-5
• IEC 61000-4-6
• IEC 61000-4-16
Console Port USB 2.0 (micro AB jack):
• Secure Shell (SSH)
Port Default IP Address LAN 1 IP = 192.168.0.189 Port 22
LAN 2 IP = 192.168.1.189 Port 22
USB 2.0 IP = 10.0.0.1 Port 22
