26 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
CHAPTER 1: BEFORE YOU START
Specifications
D20E Ethernet I/O Modules are data collection and control devices integrated with network
communication technology for smart grid and substation automation. The D20E modules
are a combination of hardware and software systems with either DNP3 TCP/IP subset
level
2 or IEC 61850 GGIO server protocols.
Each D20E module is designed and implemented with:
The input/output allocation for the four different modules:
D20E-A: 32 DC Analog Input channels (with 32 high/low alarm points)
D20E-K: 32 Control Outputs (can be configured into 4 different control output
types)
D20E-S: 64 Digital Inputs (COS and SOE)
D20E-C: 8 Control Outputs, 16 Analog Inputs and 16 Digital Inputs
Four 10/100Base-T Local Area Network interfaces supporting 2 independent networks
for redundancy;
One USB 2.0 console port.
Two DC Power Supply inputs for supporting dual mirrored power sources.
NOTE
All specifications for D20E modules are shown below. These specifications are subject to
change.
Specifications are provided for:
Digital inputs on page 27
Control outputs on page 28
Analog inputs on page 29
Power supply on page 29
Enclosure electro-magnetic capability on page 30
Environmental on page 30
Physical on page 30
Communication ports on page 31
