96 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
CHAPTER 7: CONNECTING FIELD WIRING TO THE D20E MODULE
35 Status Input 35 101 Status Wetting 1 to 64
36 Status Input 36 102 Status Wetting 1 to 64
37 Status Input 37 103 Status Wetting 1 to 64
38 Status Input 38 104 Status Wetting 1 to 64
39 Status Input 39 105 Status Wetting 1 to 64
40 Status Input 40 106 Status Wetting 1 to 64
41 Status Input 41 107 Status Wetting 1 to 64
42 Status Input 42 108 Status Wetting 1 to 64
43 Status Input 43 109 Status Wetting 1 to 64
44 Status Input 44 110 Status Wetting 1 to 64
45 Status Input 45 111 Status Wetting 1 to 64
46 Status Input 46 112 Status Wetting 1 to 64
47 Status Input 47 113 Status Wetting 1 to 64
48 Status Input 48 114 Status Wetting 1 to 64
49 Status Input 49 115 Status Wetting 1 to 64
50 Status Input 50 116 Status Wetting 1 to 64
51 Status Input 51 117 Status Wetting 1 to 64
52 Status Input 52 118 Status Wetting 1 to 64
53 Status Input 53 119 Status Wetting 1 to 64
54 Status Input 54 120 Status Wetting 1 to 64
55 Status Input 55 121 Status Wetting 1 to 64
56 Status Input 56 122 Status Wetting 1 to 64
57 Status Input 57 123 Status Wetting 1 to 64
58 Status Input 58 124 Status Wetting 1 to 64
59 Status Input 59 125 Status Wetting 1 to 64
60 Status Input 60 126 Status Wetting 1 to 64
61 Status Input 61 127 Status Wetting 1 to 64
62 Status Input 62 128 Status Wetting 1 to 64
63 Status Input 63 129 Status Wetting 1 to 64
64 Status Input 64 130 Status Wetting 1 to 64
65 External DI DC Supply (+/‒) 131 External DI DC Supply (‒/+)
66 No Connection 132 No Connection (PE GND on #10 stud)
TB2 Description TB2 Description
