92 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
CHAPTER 7: CONNECTING FIELD WIRING TO THE D20E MODULE
Table 23: D20E-K - control output module terminal block assignments
TB2 Description TB2 Description
1 External Control Output DC Supply (‒/+) 54 External Control Output DC Supply (+/‒)
2 No Connection 55 No Connection
3 No Connection 56 Interposer Current Limit Input
4 Trip1/Raise16/Normal Open1/DO1+ 57 Close1/Common1/DO1‒
5 Normal Close1 58 Trip2/Lower16/Normal Open2/DO2+
6 Close2/Common2/DO2- 59 Normal Close2
7 Trip3/Raise15/Normal Open3/DO3+ 60 Close3/Common3/DO3‒
8 Normal Close3 61 Trip4/Lower15/Normal Open4/DO4+
9 Close4/Common4/DO4‒ 62 Normal Close4
10 Trip5/Raise14/Normal Open5/DO5+ 63 Close5/Common5/DO5‒
11 Normal Close5 64 Trip6/Lower14/Normal Open6/DO6+
12 Close6/Common6/DO6‒ 65 Normal Close6
13 Trip7/Raise13/Normal Open7/DO7+ 66 Close7/Common7/DO7‒
14 Normal Close7 67 Trip8/Lower13/Normal Open8/DO8+
15 Close8/Common8/DO8‒ 68 Normal Close8
16 Trip9/Raise12/Normal Open9/DO9+ 69 Close9/Common9/DO9‒
17 Normal Close9 70 Trip10/Lower12/Normal Open10/DO10+
18 Close10/Common10/DO10‒ 71 Normal Close10
19 Trip11/Raise11/Normal Open11/DO11+ 72 Close11/Common11/DO11‒
20 Normal Close11 73 Trip12/Lower11/Normal Open12/DO12+
21 Close12/Common12/DO12‒ 74 Normal Close12
22 Trip13/Raise10/Normal Open13/DO13+ 75 Close13/Common13/DO13‒
23 Normal Close13 76 Trip14/Lower10/Normal Open14/DO14+
24 Close14/Common14/DO14‒ 77 Normal Close14
25 Trip15/Raise9/Normal Open15/DO15+ 78 Close15/Common15/DO15‒
26 Normal Close15 79 Trip16/Lower9/Normal Open16/DO16+
27 Close16/Common16/DO16‒ 80 Normal Close16
28 Trip17/Raise8/Normal Open17/DO17+ 81 Close17/Common17/DO17‒
29 Normal Close17 82 Trip18/Lower8/Normal Open18/DO18+
30 Close18/Common18/DO18‒ 83 Normal Close18
31 Trip19/Raise7/Normal Open19/DO19+ 84 Close19/Common19/DO19‒
32 Normal Close19 85 Trip20/Lower7/Normal Open20/DO20+
33 Close20/Common20/DO20‒ 86 Normal Close20
34 Trip21/Raise6/Normal Open21/DO21+ 87 Close21/Common21/DO21‒
35 Normal Close21 88 Trip22/Lower6/Normal Open22/DO22+
36 Close22/Common22/DO22‒ 89 Normal Close22
37 Trip23/Raise5/Normal Open23/DO23+ 90 Close23/Common23/DO23‒
38 Normal Close23 91 Trip24/Lower5/Normal Open24/DO24+
39 Close24/Common24/DO24‒ 92 Normal Close24
40 Trip25/Raise4/Normal Open25/DO25+ 93 Close25/Common25/DO25‒
41 Normal Close25 94 Trip26/Lower4/Normal Open26/DO26+
42 Close26/Common26/DO26‒ 95 Normal Close26
43 Trip27/Raise3/Normal Open27/DO27+ 96 Close27/Common27/DO27‒
44 Normal Close27 97 Trip28/Lower3/Normal Open28/DO28+
45 Close28/Common28/DO28‒ 98 Normal Close28
46 Trip29/Raise2/Normal Open29/DO29+ 99 Close29/Common29/DO29‒
