GE COMPANY

DIRECTION 5472001-1EN, REVISION 6OPTIMA CT680 SERIES AND OPTIMA CT670 INSTALLATION MANUAL

Page 150 Section 2.0 - Install Console Covers

Section 2.0 Install Console Covers

2.1 Time and Personnel

2.2 Tools and Test Equipment

•4mm Hex driver

2.3 Procedures

2.3.1 Console Side Covers

1.) Swing the side cover into position.

2.) Insert top edge of side cover into inside of top cover. The distance between side cover rear

edge and chassis should be about 20mm.

3.) Move side cover forward and fix it on chassis.

Figure 4-11 Place Side Cover

Required Persons Preliminary

Reqs

Procedure Finalization

1 (FE or mechanical supplier) 15 minutes labor on-site

①

②

③

Side Cover
