GE Optima CT680 Series - Host Computer Connections

GE COMPANY
DIRECTION 5472001-1EN, REVISION 6OPTIMA CT680 SERIES AND OPTIMA CT670 INSTALLATION MANUAL
Page 110 Section 3.0 - Console Connections
3.4 Host Computer Connections
NOTICE Potential for equipment damage Never connect a mouse or keyboard with the host computer
powered "ON". Doing so can destroy components within the host computer.
1.) Open the right side of the console rear panel.
Figure 2-12 NIO Rear View
2.) Connect the all cables (see Table 2-4) to the rear of Host Computer referring to the drawing
below (Figure 2-13).The drawing is also printed on the right rear door of the console.
120VAC
AC Box (5412524-2)
GND
EMC Label
WEEE LabelRating Plate
ETL Label
