DIRECTION 5472001-1EN, REVISION 6OPTIMA CT680 SERIES AND OPTIMA CT670 INSTALLATION MANUAL
Page 112 Section 3.0 - Console Connections
Figure 2-14 Host Computer (Z840) Connections
3.5 Switch Hub Connections
Switch Hub located on the left bottom of the console. Plug cables into Switch Hub on console.
Figure 2-15 Switch Hub Connections
SRV HOST RPM
UPS AW
ECG
AUX
PTR
INJ
Switch Hub Bracket
Switch Hub
Swtich Outline
