4.4.3 High and Low Alarm Contacts
The high alarm contact (HIALR) is used to detect a high alarm associated with an analog reference.
Use of this contact and the low alarm contact must be enabled during CPU configuration.
A high alarm contact passes power flow if the high alarm bit associated with the analog reference is
ON.
The low alarm contact (LOALR) detects a low alarm associated with an analog reference. Use of
this contact must be enabled during CPU configuration.
A low alarm contact passes power flow if the low alarm bit associated with the analog reference is
ON.
Operands
