GE PACSystems RX7i User Manual

Chapter 9. Diagnostics
GFK-2950C February 2018 401
9.4.6 System Configuration Mismatch (Group 11)
The fault group Configuration Mismatch occurs when the module occupying a slot is different from
that specified in the configuration file. When the GBC generates the mismatch because of a Genius
block, the second byte in the Fault Extra Data field contains the bus address of the mismatched
block.
Default action: Fatal. Configurable.
Note: If a system configuration mismatch occurs when the CPU is in RUN Mode, the fault action will
be Diagnostic regardless of the fault configuration. See Fault Parameters in PACSystems
RX7i, RX3i and RSTi-EP CPU Reference Manual, GFK-2222.
2, Genius I/O Block Model Number Mismatch
The CPU generates this fault when the configured and physical Genius I/O blocks have different
model numbers.
Correction
1) Replace the Genius I/O block with one corresponding to the configured module.
2) Update the configuration file.
Fault Extra Data for Genius I/O Block Model Number Mismatch
Byte
Value
[0]
FF (flag byte)
[1]
Serial Bus address
[2]
Installed module type (refer to Installed/Configured Module Types (Bytes 2 and 3 of Fault
Extra Data) below).
[3]
Configured module type (refer to Installed/Configured Module Types (Bytes 2 and 3 of Fault
Extra Data) below).
Installed/Configured Module Types (Bytes 2 and 3 of Fault Extra Data)
Number
Description
Decimal
Hexadecimal
4
4
Genius Network Interface (GENI)
5
5
Phase B Hand Held Monitor
6
6
Phase B Series Six GBC with Diagnostics
7
7
Phase B Series Six GBC without Diagnostics
8
8
PLCM/Series Six
9
9
PLCM/Series 90-70
10
A
Series 90-70 Single Channel Bus Controller
11
B
Series 90-70 Dual Channel Bus Controller
12
C
Series 90-10 Genius Communications Module
13
D
Series 90-30 Genius Communications Module
32
20
High Speed Counter
69
45
Phase B 115Vac 8-point (2 amp) Grouped Block
70
46
Phase B 115Vac/125Vdc 8-point Isolated Block
70
46
Phase B 115Vac/125Vdc 8-point Isolated Block without Failed Switch
71
47
Phase B 220Vac 8-point Grouped Block
