9.5 I/O Fault Descriptions and Corrective Actions
The I/O fault table reports the following data about faults:
▪ Fault Group
▪ Fault Action
▪ Fault category
▪ Fault type
▪ Fault description
All faults have a fault category, but a fault type and fault group may not be listed for every fault. To
view the detailed information pertaining to a fault, click the fault entry in the I/O Fault Table.
Note: The model number mismatch and I/O type mismatch faults are reported in the controller
fault table under the System Configuration Mismatch group. They are not reported in the I/O
fault table.
9.5.1 Fault Extra Data
An I/O fault table entry contains up to 21 bytes of I/O fault extra data that contains additional
information related to the fault. Not all entries contain I/O fault extra data.
9.5.2 I/O Fault Groups
Group Number
Group Name
Default Fault Action
16
Configurable
2
Loss of or Missing IOC
Diagnostic
Yes
3
Loss of or Missing I/O module or network
Device
Diagnostic
Yes
6
Addition or Reset of, or Extra IOC
N/A
No
7
Addition of or Extra I/O module or network
Device
N/A
No
9
IOC or I/O Bus Fault
Diagnostic
Yes
10
I/O Module Fault
N/A
No
15
IOC Software Failure
Same As Group 2
19
Yes
16
Module Software Failure
N/A
No
28
PROFINET Alarms
Diagnostic
No
133
Genius Block Address Mismatch
N/A
No
19
The fault action for the IOC Software Failure group 15 always matches the action used by the Loss of or Missing IOC
group 2. If the Loss of or Missing IOC group is configured, the IOC Software Failure group is also configured to take the
same fault action.
