5.12.5 Convert DINT to DWORD
When DINT_TO_DWORD receives data, it converts the input double-
precision signed integer (DINT) data into the equivalent DWORD (32-bit
bit string) value, which it outputs to Q. DINT_TO_DWORD does not
change the original DINT data.
The output data can be used directly as input for another program
function. The function passes data to Q unless the data is out of range.
Operands
Parameter
Description
Allowed Types
Allowed Operands
Optional
Solve Order
Calculated by the FBD editor.
NA
NA
No
IN
The value to convert to DWORD.
DINT
All except S, SA, SB, and
SC
No
Q
The DWORD equivalent value of the
original value in IN. 0  Q 
4,294,967,295.
DWORD
All except S, SA, SB, SC
and constant
No
