GE PACSystems RX7i User Manual

Chapter 3. Program Data
GFK-2950C February 2018 47
3.8.2 %SA, %SB, and %SC References
Note: %SA, %SB, and %SC contacts are not set or reset until the input scan phase of the sweep
following the occurrence of the fault or a clearing of the fault table(s). %SA, %SB, and %SC
contacts can also be set or reset by user logic and CPU monitoring devices.
Reference
System
Variable
Definition
%SA0001
#PB_SUM
Set when a checksum calculated on the application program does not match the
reference checksum. If the fault was due to a temporary failure, the condition can
be cleared by again storing the program to the CPU. If the fault was due to a hard
RAM failure, then the CPU must be replaced.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SA0002
#OV_SWP
Set when the CPU detects that the previous sweep took longer than the time
specified by the user. To clear this bit, clear the CPU fault table or power cycle the
CPU. Only occurs if the CPU is in Constant Sweep mode.
%SA0003
#APL_FLT
Set when an application fault occurs. To clear this bit, clear the CPU fault table or
power cycle the CPU.
%SA0009
#CFG_MM
Set when a configuration mismatch fault is logged in the fault tables. To clear this
bit, clear the CPU fault table or power cycle the CPU.
%SA0008
#OVR_TMP
Set when the operating temperature of the CPU exceeds the normal operating
temperature, 58ºC. To clear this bit, clear the CPU fault table or power cycle the
CPU.
%SA0010
#HRD_CPU
Set when the diagnostics detects a problem with the CPU hardware. To clear this
bit, clear the CPU fault table or power cycle the CPU.
%SA0011
#LOW_BAT
The low battery indication is not supported for all CPU modules. For details, refer
to Battery Status (Group 18) in Chapter 9.
The CPU may set this contact when an I/O module or special-purpose module has
reported a low battery. In this case, a fault will be reported in the I/O Fault Table.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SA0012
#LOS_RCK
Set when an expansion rack stops communicating with the CPU. To clear this bit,
clear the CPU fault table or power cycle the CPU.
%SA0013
#LOS_IOC
Set when a Bus Controller stops communicating with the CPU.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0014
#LOS_IOM
Set when an I/O module stops communicating with the CPU.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0015
#LOS_SIO
Set when an option module stops communicating with the CPU.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SA0017
#ADD_RCK
Set when an expansion rack is added to the system.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SA0018
#ADD_IOC
Set when a Bus Controller is added to a rack.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0019
#ADD_IOM
Set when an I/O module is added to a rack.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0020
#ADD_SIO
Set when an intelligent option module is added to a rack.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0022
#IOC_FLT
Set when a Bus Controller reports a bus fault, a global memory fault, or an IOC
hardware fault. To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0023
#IOM_FLT
Set when an I/O module reports a circuit or module fault.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0027
#HRD_SIO
Set when a hardware failure is detected in an option module.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
