Chapter 3. Program Data
48 PACSystems* RX7i, RX3i and RSTi-EP CPU Programmer's Reference Manual GFK-2950C
Reference
System
Variable
Definition
%SA0029
#SFT_IOC
Set when there is a software failure in the I/O Controller.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0030
#PNIO_ALARM
A PROFINET alarm has been received and an I/O fault has been logged in group 28.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0031
#SFT_SIO
Set when an option module detects an internal software error.
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0032
#SBUS_ER
Set when a bus error occurs on the VME bus backplane
To clear this bit, clear the I/O Fault Table or power cycle the CPU.
%SA0081 –
%SA0112
Set when a user-defined fault is logged in the CPU fault table.
To clear these bits, clear the CPU fault table or power cycle the CPU. For more
information, see discussion of SVC_REQ 21: User-Defined Fault Logging in Chapter
7.
%SB0001
#WIND_ER
Set when there is not enough time to start the Programmer Window in Constant
Sweep mode.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SB0009
#NO_PROG
Set when the CPU powers up with memory preserved, but no user program is
present. Cleared when the CPU powers up with a program present or by clearing
the CPU fault table.
%SB0010
#BAD_RAM
Set when the CPU detects corrupted RAM memory at power-up. Cleared when the
CPU detects that RAM memory is valid at power-up or by clearing the CPU fault
table.
%SB0011
#BAD_PWD
Set when a password access violation occurs. Cleared when
the CPU fault table is cleared or when the CPU is power cycled.
%SB0012
#NUL_CFG
Set when an attempt is made to put the CPU in RUN Mode when there is no
configuration data present.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SB0013
#SFT_CPU
Set when the CPU detects an error in the CPU operating system software.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SB0014
#STOR_ER
Set when an error occurs during a programmer store operation.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SB0016
#MAX_IOC
Set when more than 32 IOCs are configured for the system.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SB0017
#SBUS_FL
Set when the CPU fails to gain access to the bus.
To clear this bit, clear the CPU fault table or power cycle the CPU.
%SC0009
#ANY_FLT
Set when any fault occurs that causes an entry to be placed in the CPU or I/O Fault
Table. Cleared when both fault tables are cleared or when the CPU is power cycled.
%SC0010
#SY_FLT
Set when any fault occurs that causes an entry to be placed in the CPU fault table.
Cleared when the CPU fault table is cleared or when the CPU is power cycled.
%SC0011
#IO_FLT
Set when any fault occurs that causes an entry to be placed in the I/O Fault Table.
Cleared when the I/O Fault Table is cleared or when the CPU is power cycled.
%SC0012
#SY_PRES
Set as long as there is at least one entry in the CPU fault table. Cleared when the
CPU fault table is cleared.
%SC0013
#IO_PRES
Set as long as there is at least one entry in the I/O Fault Table. Cleared when the
I/O Fault Table is cleared.
%SC0014
#HRD_FLT
Set when a hardware fault occurs. Cleared when both fault tables are cleared or
when the CPU is power cycled.
%SC0015
#SFT_FLT
Set when a software fault occurs. Cleared when both fault tables are cleared or
when the CPU is power cycled.
