Chapter 9. Diagnostics
434 PACSystems* RX7i, RX3i and RSTi-EP CPU Programmer's Reference Manual GFK-2950C
9.5.6 Addition of Block (Category 3)
The fault category Addition of Block applies only to Genius devices. There are no fault types or fault
descriptions associated with this category.
The Genius operating software generates this error when it detects that a Genius block that stopped
communicating with the controller starts communicating again.
Action: Diagnostic.
Correction
Informational only. None required.
Fault Extra Data for Addition of Block
The Addition of Block fault provides four bytes of fault extra data. The second byte contains the block
configuration and is encoded as shown in the following table. The third byte specifies the number of
input circuits possibly used, and the fourth byte specifies the number of output circuits possibly
used.
Block Configuration (Byte 2)
Value
Description
1
Block is configured for inputs only.
2
Block is configured for outputs only.
3
Block is configured for inputs and outputs (grouped block).
