Number
Description
Decimal
Hexadecimal
72
48
Phase B 24-48Vdc 16-point Proximity Sink Block
72
48
Phase B 24Vdc 16-point Proximity Sink Block
73
49
Phase B 24-48Vdc 16-point Source Block
73
49
Phase B 24Vdc 16-point Proximity Source Block
74
4A
Phase B 12-24Vdc 32-point Sink Block
75
4B
Phase B 12-24Vdc 32-point Source Block
76
4C
Phase B 12-24Vdc 32-point 5V Logic Block
77
4D
Phase B 115Vac 16-point Quad State Input Block
78
4E
Phase B 12-24Vdc 16-point Quad State Input Block
79
4F
Phase B 115/230Vac 16-point Normally Open Relay Block
80
50
Phase B 115/230Vac 16-point Normally Closed Relay Block
81
51
Phase B 115Vac 16-point AC Input Block
82
52
Phase B 115Vac 8-point Low-Leakage Grouped Block
127
7F
Genius Network Adapter (GENA). Refer to GENA Application ID Numbers
below.
131
83
Phase B 115Vac 4-input, 2-output Analog Block
132
84
Phase B 24Vdc 4-input, 2-output Analog Block
133
85
Phase B 220Vac 4-input, 2-output Analog Block
134
86
Phase B 115Vac Thermocouple Input Block
135
87
Phase B 24Vdc Thermocouple Input Block
136
88
Phase B 115Vac RTD Input Block
137
89
Phase B 24/48Vdc RTD Input Block
138
8A
Phase B 115Vac Strain Gauge/mV Analog Input Block
139
8B
Phase B 24Vdc Strain Gauge/mV Analog Input Block
140
8C
Phase B 115Vac 4-input, 2-output Current Source Analog Block
141
8D
Phase B 24Vdc 4-input, 2-output Current Source Analog Block
GENA Application ID Numbers
If the model number is 7F hex (Genius Network Adapter), the block may be one of the following. (The
GENA Application ID is shown for reference.)
Number
Decimal
Hexadecimal
Description
131
83
115Vac/230Vac/125Vdc Power Monitor Module
132
84
24/48Vdc Power Monitor Module
160
A0
Genius Remote 90-70 Rack Controller
