Chapter 9. Diagnostics
404 PACSystems* RX7i, RX3i and RSTi-EP CPU Programmer's Reference Manual GFK-2950C
Correction
1) Replace the Analog Expander module with one corresponding to configured module.
2) Update the configuration file.
9, Genius I/O Block Size Mismatch
The CPU generates this error when block configuration size does not match the configured size.
Correction
Reconfigure the block.
Fault Extra Data for Genius I/O Block Size Mismatch
Byte
Value
[0]
FF
[1]
Bus address
[2]
Module’s broadcast data length
[3]
Configured module’s broadcast data length
A hex/10 decimal, Unsupported Feature
Configured feature not supported by this revision of the module.
Correction
1) Update the module to a revision that supports the feature.
2) Change the module configuration.
Fault Extra Data for Unsupported Feature
Byte
Value
[8]
Contains a reason code indicating what feature is not supported.
0x5 – GBC revision too old
0x6 – Only supported in main rack
E hex/14 decimal, LAN Duplicate MAC Address
This LAN Interface module has the same MAC address as another device on the LAN. The module is
off the network.
Correction
1) Change the module’s MAC address.
2) Change the other device’s MAC address.
F hex/15 decimal, LAN Duplicate MAC Address Resolved
Previous duplicate MAC address has been resolved. The module is back on the network. This is an
informational message. No correction required.
10 hex/16 decimal, LAN MAC Address Mismatch
MAC address programmed by softswitch utility does not match configuration stored from software.
Correction
Change MAC address on softswitch utility or in software.
