ActionStep
On the displayed page in the Start Protocol:2
1
Type the Result name and click Browse to change the Location of where
the result is saved if necessary.
2
Select the correct Bag size (two sizes are listed in dual mode).
3
Click OK.
Result: The manual run starts.
Start a method run
Follow the instructions below to start a method run.
The system can be controlled manually from the Process Picture after the
method run has been started.
Tip:
ActionStep
Open the System Control module and click the icon Open Method Navigator.1
Result: The Method Navigator pane opens.
Select the method to run, and click the Run icon.2
Result: The Start Protocol dialog for the method run opens.
ReadyToProcess WAVE 25 Operating Instructions 29009597 AD 133
5 Operation
5.2 Start and configure the system
5.2.5 Start a run
