Equipment dimensions and
weight
The table below lists the outer dimensions and weights of the bioreactor system units.
Weight (kg)Dimensions, W x D x H (mm)System unit
24.0404 x 560 x 205Rocker
4.8276 x 360 x 117CBCU
3.8275 x 280 x 115Pump
4.5475 x 430 x 60Tray 10
7.3740 x 480 x 70Tray 20
9.5800 x 610 x 70Tray 50
1.7475 x 430 x 230Lid 10
3.3740 x 480 x 245Lid 20
3.9800 x 610 x 260Lid 50
Environmental conditions
The following general requirements must be fulfilled:
•
The room must have forced ventilation, adapted for use of CO
2
, O
2
and N
2
.
•
The system units should not be exposed to sources of heat, such as direct sunlight
The installation site must comply with the following specifications.
Environmental requirements
RequirementParameter
Indoor use onlyAllowed location
15°C to 32°CAmbient temperature, operation
20% to 80%, noncondensingRelative humidity, operating
800 to 1060 mbarAtmospheric pressure
Up to 2000 mAltitude, operation
