80209C_MHW_850-1650-1850_02-2020_ENG_pag. 123
4.15.1. PID.N - Selecting PID for parameters to be configured
Acronym Scrolling message Submenu Attributes
PID.N PID NUMBER PID.GR R W
The parameter shows and sets the identifying number of the available PID.
Unit of measurement: Number
Options: 1...2
4.15.2. PID.G.N - Selecting PID for parameters group to be configured
Acronym Scrolling message Submenu Attributes
PID.G.N PID PARAMETERS GROUP NUMBER PID.GR R W
The parameter shows and sets the parameter group to be configured, identified by its number.
Unit of measurement: Number
Options: 1...PD.G.N = Numerical identification where PID.G.N is the total number of groups of parameters
set on the MODE submenu
4.15.3. H.PB - Proportional heating band or hysteresis in ON-OFF control
Acronym Scrolling message Submenu Attributes
H.PB PID.GR.1 (or PID.GR.2…PID.GR.4) HEATING PROPORTIONAL BAND OR ON/
OFF HYST
PID.GR R W
The parameter shows and sets the proportional heating band or hysteresis in the ON-OFF control, calculated as a per-
centage of full scale of the main or auxiliary input.
Unit of measurement: %
Options: 0.0...999.9
4.15.4. H.IT - Integral heating time
Acronym Scrolling message Submenu Attributes
H.IT PID.GR.1 (or PID.GR.2…PID.GR.4) HEATING INTEGRAL TIME PID.GR R W
The parameter shows and sets the integral heating time.
Unit of measurement: Minutes
Options: 0.00...99.99
4.15.5. H.DT - Derivative heating time
Acronym Scrolling message Submenu Attributes
H.DT PID.GR.1 (or PID.GR.2…PID.GR.4) HEATING DERIVATIVE TIME PID.GR R W
The parameter shows and sets the derivative heating time.
Unit of measurement: Minutes
Options: 0.00...99.99
