80209C_MHW_850-1650-1850_02-2020_ENG_pag. 143
4.19.6. MAST.N - Setting the Master communication parameter number
Acronym Scrolling message Submenu Attributes
MAST.N OUT.AN.1 (o OUT.AN.2) MASTER PARAMETER NUMBER OUT.AN R W
This parameter shows and sets the Master parameter number associated with the output.
This parameter only appears if the F.ou.C parameter = MASTER.
Unit of measurement: Number
Options: 1...20
4.19.7. CY.TIM – Output cycle time
Acronym Scrolling message Submenu Attributes
CY.TIM OUT.AN.1 (o OUT.AN.2) CYCLE TIME OUT.AN R W
This parameter shows and sets the output partialisation period.
The parameter will appear if the StAt parameter = DI.PWM, IN.PWM.
Partialisation period is the cycle time, that is, the sum of ON time and OFF time proportional to the value to be retransmit-
ted.
Example
If the value to be retransmitted is 25% and the duration of the cycle is 10.0 seconds, the output will be active for 2.5
seconds and deactivated for 7.5 seconds.
Unit of measurement: Seconds
Options: 1...200
4.19.8. LO.SCL - Scale minimum
Acronym Scrolling message Submenu Attributes
LO.SCL OUT.AN.1 (o OUT.AN.2) LOW LIMIT ANALOG OUTPUT OUT.AN R W
The parameter shows and sets the scale minimum, which corresponds to minimum output value in voltage or current.
Each time you set the power control output on parameter FuNC, the parameter value is forced to 0.
The scale limit is ignored if the output is assigned to an MFB output (or calculated directly by an MFB.
Unit of measurement: Scale points of quantity assigned to analog output.
Options: -1999...9999
4.19.9. HI.SCL - Scale maximum
Acronym Scrolling message Submenu Attributes
HI.SCL OUT.AN.1 (o OUT.AN.2) HIGH LIMIT ANALOG OUTPUT OUT.AN R W
The parameter shows and sets the scale maximum, which corresponds to minimum output value in voltage or current.
Each time you set the power control output on parameter FuNC, the parameter value is forced to 1000.
The scale limit is ignored if the output is assigned to an MFB output (or calculated directly by an MFB).
Unit of measurement: Scale points of quantity assigned to analog output.
Options: -1999...9999
