4.29.3. X1 - Abscissa of first linearisation point
Acronym Scrolling message Submenu Attributes
X1 LIN.4.P.1 (0 LIN.4.P.2 o LIN.4.P.3) CUSTOM 4 POINT LINEARIZATION STEP LIN.4.P RW
This parameter permits setting of the abscissa of the first linearisation point in the four points. If the RD.ADJ option is
active (parameter Md.4P), an editable value will be displayed, while if the CALIB option is active, the value of the corre-
sponding input is displayed, which may be edited with a calibrator or related instrument.
Unit of measurement: Points on the scale
Options: -1999..9999
4.29.4. Y1- Ordinate of the first 4-point linearisation point
Acronym Scrolling message Submenu Attributes
Y1 LIN.4.P.1 (0 LIN.4.P.2 o LIN.4.P.3) CUSTOM 4 POINT LINEARIZATION STEP LIN.4.P RW
This parameter may be used to set the ordinate of the first 4-point linearisation point.
Unit of measurement: Points on the scale
Options: -1999..9999
4.29.5. X2 - Abscissa of second linearisation point
Acronym Scrolling message Submenu Attributes
X2 LIN.4.P.1 (0 LIN.4.P.2 o LIN.4.P.3) CUSTOM 4 POINT LINEARIZATION STEP LIN.4.P RW
This parameter permits setting of the abscissa of the second linearisation point in the four points.
Unit of measurement: Points on the scale
Options: -1999..9999
4.29.6. Y2- Ordinate of the second 4-point linearisation point
Acronym Scrolling message Submenu Attributes
Y2 LIN.4.P.1 (0 LIN.4.P.2 o LIN.4.P.3) CUSTOM 4 POINT LINEARIZATION STEP LIN.4.P RW
This parameter may be used to set the ordinate of the second 4-point linearisation point.
Unit of measurement: Points on the scale
Options: -1999..9999
