4.18.12. FAULT - State of output with broken input
Acronym Scrolling message Submenu Attributes
FAULT OUTPU.1 (o OUTPU.2 … OUTPU.4) FAULT OUTPUT STATE OUTPU R W
The parameter shows and sets the state (ON, OFF) that the output assumes in case of sensor fault (Err, Sbr, ...), on main
input IN.1 or auxiliary input IN.2, if the output is direct or inverse and automatic operation mode.
Unit of measurement: -
Options: OFF.1 = Output OFF in case of fault on main input IN.1
On.1 = Output ON in case of fault on main input IN.1
nOnE = Output continues to function normally
if the model with auxiliary input:
OFF.2 = Output OFF in case of fault on auxiliary input IN.2
On.2 = Output ON in case of fault on auxiliary input IN.2
OF.12 = Output OFF in case of fault on input IN.1 or IN.2
On.12 = Output ON in case of fault on input IN.1 or IN.2
4.18.13. MSG.OU - Selecting the output message
Acronym Scrolling message Submenu Attributes
MSG.OU OUTPU.1 (o OUTPU.2 … OUTPU.4) NUMBER OF SCROLLING MESSAGE AT
OUTPUT ACT
OUTPU R W
The parameter shows and sets the number of the message assigned to activation of the output, i.e., the scrolling messa-
ge shown on the display.
For more information on scrolling messages, see paragraph “3.1.2.2. Scrolling messages” on page <?>.
If the parameter is set to “0” no message will be displayed when the output is activated.
The same message number can be assigned to different outputs.
Unit of measurement: Message number
Options: 0...25 (with LAnG=LANG1 or LANG2 or LANG3)
0…75 (with LAnG=NONE)
4.18.14. LO.C – Low limit for continuous output / HI.C
Acronym Scrolling message Submenu Attributes
LO.C LOW LIMIT CONTINUE OUTPUT OUTPU R W
This parameter shows and sets the low limits of the scale, corresponding to the minimum output voltage or current.
Every time the F.ou.C parameter of power control output is set, the value of this parameter is forced to 0.
This parameter only applies if Output 1 is of the CONT.A or CONT.C type.
Unit of measurement: Points on the scale of quantities associated with continuous output
Options: -1999...9999
4.18.15. HI.C – Massimo di scala per uscita continua
Acronym Scrolling message Submenu Attributes
HI.C HIGH LIMIT CONTINUE OUTPUT OUTPU R W
This parameter shows and sets the high limits of the scale, corresponding to the maximum output voltage or current.
Every time the F.ou.C parameter of power control output is set, the value of this parameter is forced to 1000.
This parameter only applies if Output 1 is of the CONT.A or CONT.C type.
Unit of measurement: Points on the scale of quantities associated with continuous output
Options: -1999...9999
