4.9.10. LO.SCL - Lower limit of scale
Acronym Scrolling message Submenu Attributes
LO.SCL INPUT.1 (or INPUT.2 or INPUT.3) INPUT LOW LIMIT INPUT R W
The parameter shows and sets the lower limit of the measurement scale used for the main or auxiliary input, based on input
(or sensor) type, unit of measurement, and number of decimals selected.
The upper value of LO.SCL is not limited by the value of HI.SCL.
Unit of measurement: The one set with the Unit parameter
Options: A numerical value within the temperature range of the input or sensor
4.9.11. HI.SCL - Upper limit of scale
Acronym Scrolling message Submenu Attributes
HI.SCL INPUT.1 (or INPUT.2 or INPUT.3) INPUT HIGH LIMIT INPUT R W
The parameter shows and sets the upper limit of the measurement scale used for the main or auxiliary input, based on
input (or sensor) type, unit of measurement, and number of decimals selected.
The lower value of HI.SCL is limited by the value of LO.SCL.
Unit of measurement: The one set with the Unit parameter
Options: A value in the interval corresponding to the input or sensor type (see tables for LO.SCL parameter).
Type Unit = °C
DEC.P = 0
Unit = °F
DEC.P = 0
J.TC -210…1200 -346…2192
K.TC -270…1372 -454…2502
R TC -50…1768 -58…3214
S TC -50…1768 -58…3214
T.TC -270…400 -454…752
C.TC 0…2315 32…4199
D.TC 0…2315 32…4199
B 40…1820 104…3308
E -270…1000 -454…1832
L -200…900 -328…1652
L-GOST -200…800 -328…1472
U -200…600 -328…1112
G 0…2315 32…4199
N -270…1300 -454…2372
PT2.TC 0…1888 32…3430
INFR1 10...70 50...158
INFR2 60...120 140...248
INFR3 115...165 239...329
INFR4 140...260 284...500
PT100 -200...850 -328...1562
PT.LIM -50...250 -58...212
JPT10 -200...600 -328...1112
Unit = °C
DEC.P = 0
Unit = °F
DEC.P = 0
60MV -1999...9999 -199.9...999.9
20MA -1999...9999 -199.9...999.9
4-20M -1999...9999 -1999...9999
10V -1999...9999 -1999...9999
2-10V -1999...9999 -1999...9999
5V -1999...9999 -1999...9999
1-5V -1999...9999 -1999...9999
1V -1999...9999 -1999...9999
0.2-1V -1999...9999 -1999...9999
2.4 VHI -1999...9999 -1999...9999
1.2VHI -1999...9999 -1999...9999
C1VH -1999...9999 -1999...9999
C.20MA -1999...9999 -1999...9999
C.4-20 -1999...9999 -1999...9999
C.10V -1999...9999 -1999...9999
C.2-10 -1999...9999 -1999...9999
C.5V -1999...9999 -1999...9999
C.1-5V -1999...9999 -1999...9999
C.1V -1999...9999 -1999...9999
C.0.2-1 -1999...9999 -1999...9999
C2.4 VH -1999...9999 -1999...9999
C1.2VH -1999...9999 -1999...9999
