4.10. Submenu IN.CT - Configuration of current inputs
Acronym Scrolling message Password Description
IN.CT CT INPUT CONFIG Level 1 Lets you configure the inputs of the controller’s current trans-
formers.
IN.CT.N
FILT
HI.SCL
OF.SCL
Configuring current
transformers
98
Digital filter 98
Maximum scale limit 98
Limit scale correction 98
Parameter Pag.
4.10.1. Functional diagram
Low pass filter
FILT page.
98
Scale limit
HI.SCL page.
98
Offset
OF.SCL page.
98
Input signal
from current
transformer
Input value (CURRx)
To Next Page
