80209C_MHW_850-1650-1850_02-2020_ENG_pag. 167
4.26.6. IP.AD4 – Address IP 4
Acronym Scrolling message Submenu Attributes
IP.AD4 IP ADDRESS ETHER R W
This parameter shows the IP 4 address identifying the controller in an Ethernet network.
The parameter is the first field in the complete IP address (xxx.xxx.xxx.xxx).
Unit of measurement: Number
Options: 0...255
4.26.7. SUB.M1 – Subnet mask 1
Acronym Scrolling message Submenu Attributes
SUB.M1 SUBNET MASK ETHER R W
This parameter shows the Subnet mask 1 identifying the controller in an Ethernet network.
The parameter is the first field in the complete Subnet mask (xxx.xxx.xxx.xxx).
Unit of measurement: Number
Options: 0...255
4.26.8. SUB.M2 – Subnet mask 2
Acronym Scrolling message Submenu Attributes
SUB.M2 SUBNET MASK ETHER R W
This parameter shows the Subnet mask 2 identifying the controller in an Ethernet network.
The parameter is the first field in the complete Subnet mask (xxx.xxx.xxx.xxx).
Unit of measurement: Number
Options: 0...255
4.26.9. SUB.M3 – Subnet mask 3
Acronym Scrolling message Submenu Attributes
SUB.M3 SUBNET MASK ETHER R W
This parameter shows the Subnet mask 3 identifying the controller in an Ethernet network.
The parameter is the first field in the complete Subnet mask (xxx.xxx.xxx.xxx).
Unit of measurement: Number
Options: 0...255
4.26.10. SUB.M4 – Subnet mask 4
Acronym Scrolling message Submenu Attributes
SUB.M4 SUBNET MASK ETHER R W
This parameter shows the Subnet mask 4 identifying the controller in an Ethernet network.
The parameter is the first field in the complete Subnet mask (xxx.xxx.xxx.xxx).
Unit of measurement: Number
Options: 0...255
