Every operator has a freely accessible menu (no password
required) on which he can configure some controller
parameters.
The User Configuration menu can be built according to need
with the GF_express software, grouping up to 100 parameters
from those available for controller configuration (see chapter
“4. Configuration” on page “4. CONFIGURATION” on page
<?>).
The parameters that may be selected to build the user set-up
menu include PASS0 and PASS1; it may be useful to submit
a password to the parameters of the user menu.
7.6. Configuration (User menu)
The controller leaves the factory with a preconfigured user
configuration menu (shown below for models:
850-x-xxx-00000-x-xxx and 1650-x-xxx-00000-x-xxx).
This menu can subsequently be modified. The related
parameters are shown for models with options; the complete
list of parameters is shown on the GF_eXpress user menu
page.
Press the
key to access the User Configuration menu.
GF_eXpress can be used to set the generic user menu
parameter to set automatic back to PV\Home when
positioned on the parameter and no key is pressed within
15 seconds.
Description Unit of misura Valid values Notes
SETP1
ALRM1
ALRM2
ALRM3
ALRM4
AL.ACK
MS.ACK
OUT.P1
Visualizzazione Home
Local setpoint 1 scale points LO.SP1...HI.SP1
Alarm 1 limit scale points
LO.AL1...HI.AL1
-999...999
If absolute alarm.
If deviation alarm.
Alarm 2 limit scale points
LO.AL1...HI.AL1
-999...999
If absolute alarm.
If deviation alarm.
Alarm 3 limit scale points
LO.AL1...HI.AL1
-999...999
If absolute alarm.
If deviation alarm.
Alarm 4 limit scale points
LO.AL1...HI.AL1
-999...999
If absolute alarm.
If deviation alarm.
Reset alarms latch and
LBA alarm
Off
On
Appears if at least one alarm with
latch was set or if LBA alarm was
enabled.
The reset command is tempo-
rary and is not saved.
Reset scrolling message
Off
On
Appears if a scrolling message is present.
The reset command is temporary and is
not saved.
Control output value 1
-100.0...100.0
On / OFF
Value Read Only
