80209C_MHW_850-1650-1850_02-2020_ENG_pag.
155
4.23.
Submenu TIMER - Configurazione parametri timer
Acronym
Scrolling message
Password
Description
TIMER
TIMER MANAGER
Level 2
Lets you configur
e the timer parameters.
The submenu appears only if the Timer function was enabled
on the MODE submenu.
TIME.N
FunC
St.St
S.S.t
rESE
rES.t
BAND
End
TIMER
MSG.TM
Selecting timer
157
Selecting timer
function
157
Selecting the Start/
Stop timer command
157
Defining the Start/Stop
timer command logic
157
Selecting the Reset
timer command
158
Defining the Reset
timer command logic
158
Timer count band
158
Selecting the function
activated at end of
count
158
Timer value
159
Selection of the
message associa-
ted with the end of
counting
159
Parameter
Pag.
156
