80209C_MHW_850-1650-1850_02-2020_ENG_pag. 179
P.R.TIM = Program total theoretical residual time (only for model 850)
IN1 = Main input
if model with auxiliar input 2
IN3 = Auxiliar input 2
if model with Modbus Master serial and Master parameter configured:
MAS.01 = Master value 1
MAS.02 = Master value 2
MAS.03 = Master value 3
MAS.04 = Master value 4
MAS.05 = Master value 5
MAS.06 = Master value 6
MAS.07 = Master value 7
MAS.08 = Master value 8
MAS.09 = Master value 9
MAS.10 = Master value 10
MAS.11 = Master value 11
MAS.12 = Master value 12
MAS.13 = Master value 13
MAS.14 = Master value 14
MAS.15 = Master value 15
MAS.16 = Master value 16
MAS.17 = Master value 17
MAS.18 = Master value 18
MAS.19 = Master value 19
MAS.20 = Master value 20
4.28.8. BAR.2 - Selecting bargraph 2 display
Acronym Scrolling message Submenu Attributes
bAr.2 HOME.1 (o HOME.2) BARGRAPH FUNCTION HOME R W
The parameter shows and sets the display assigned to the bargraph 2.
The parameter appears only if the controller is 1650 or 1850.
The parameter appears only if parameter bAr.E is at
- ON.ALL and NO.FRA (on 1650)
- ON.ALL, ON.AL1, NO.FRA and NO.FR1(on 1850)
Unit of measurement: -
Options: PV = Process variable
SETP = Local setpoint / manual power or active setpoint, in case of enabling Multiset function,
setpoint gradient, remote setpoint, and programmer (if enabled) (LED SP on)
SSP = Active setpoint ( LED SP on)
f the model with auxiliary input
IN2 = Auxiliary input
OUT.P = Power control output
SP-PV = Deviation |SP-PV|
HEAT = Heating power output with 0...100% control
COOL = Cooling power output with 0...100% control
HE+CO = Power control output -100...100% (positive for heating, negative for cooling)
if the model with CT1+CT2:
CURR1 = Current input CT1
CURR2 = Current input CT2
if ENERG function enabled and model with CT1+CT2:
CURR = Load current (on 1850 LED A on)
if the ENERG function is enabled:
OUT.KW = Power on load
