80209C_MHW_850-1650-1850_02-2020_ENG_pag. 130
if the Programmer 1 and 2 function is enabled in parameter PROGR on the EN.FUN menu:
(for details, see paragraph “5.13. Setpoint programmer” on page <?>):
P.P12.1 = Select program for PROGR.1 and for PROGR.2 bit 1
P.P12.2 = Select program for PROGR.1 and for PROGR.2 bit 2
P.P12.3 = Select program for PROGR.1 and for PROGR.2 bit 3
P.SS12 = START/STOP PROGR.1 and PROGR.2 programmer time base
P.ST12 = START PROGR.1 and PROGR.2 programmer time base
P.SP12 = STOP and PROGR.1 e PROGR.2 programmer time base
P.RS12 = RESET and PROGR.1 e PROGR.2 programmer time base
P.SK12 = SKIP to end program (end cycle) PROGR.1 and PROGR.2
ST.S12 = SKIP to end step PROGR.1 and PROGR.2
ST.E12 = STEP ENABLE 1/2: input with consent function at start of PROGR.1 and PROGR.2 step
If valve model with auxiliary input present, function FUnC=VALV.P and custom linear type,
and with one output configured as V.OPEN and one configured as V.CLOS:
VALV.P = Calibrazione ingresso ausiliario
4.17.5. ST.EN.N - Setting assigned consent number
Acronym Scrolling message Submenu Attributes
ST.EN.N IN.DIG.1 (o IN.DIG.2 … IN.DIG.5) ENABLE NUMBER IN.DIG R W
The parameter shows and sets the consent number assigned to the digital input identified by I.DIG.N.
The parameter appears if the parameter F.in.x = ST.EN1, ST.EN2 or ST.E12.
Unit of measurement: Number
Options: 1...4
4.17.6. PRE.SW - Prescaler setting for number of input switchings
Acronym Scrolling message Submenu Attributes
PRE.SW IN.DIG.1 (o IN.DIG.2 … IN.DIG.5) PRESCALER FOR SWITCHING CYCLES IN.DIG R W
The parameter shows and sets the prescaler for the number of switchings of the digital input with CY.CNT function.
Unit of measurement: Number
Options: 1...9999
4.17.7. SWTCH - Number of input switching setting for signaling
Acronym Scrolling message Submenu Attributes
SWTCH IN.DIG.1 (o IN.DIG.2 … IN.DIG.5) NUMBER OF SWITCHING CYCLES IN.DIG R W
The parameter shows and sets the number of switchings of the digital input with CY.CNT function, which if exceeded
generates the scrolling message DIGITAL INPUT SWITCH ALARM.
The function is disabled if the parameter equals “0”.
Unit of measurement: Number
Options: 1...9999
