80209C_MHW_850-1650-1850_02-2020_ENG_pag. 80
4.8.18. ENBL.3 - Consent 3 to execute step
Acronym Scrolling message Submenu Attributes
ENBL.3 PR.STP.1 (o PR.STP.2…PR.STP.192) STEP ENABLE FOR STEP START se
modalità“Programmatore semplificato”disattiva; o PR.STP.1…PR.STP.16 STEP
ENABLE FOR STEP START se modalità“Programmatore semplificato”attiva.
PR.STP R W
The parameter shows and sets consent 3 condition to enable execution of the step.
See ENBL.1 for details.
4.8.19. ENBL.4 - Consent 4 to execute step
Acronym Scrolling message Submenu Attributes
ENBL.4 PR.STP.1 (o PR.STP.2…PR.STP.192) STEP ENABLE FOR STEP START se
modalità“Programmatore semplificato”disattiva; o PR.STP.1…PR.STP.16 STEP
ENABLE FOR STEP START se modalità“Programmatore semplificato”attiva.
PR.STP R W
The parameter shows and sets consent 4 condition to enable execution of the step.
See ENBL.1 for details.
4.8.20. EN.ST.N - Other programmer step as consent to execute step
Acronym Scrolling message Submenu Attributes
EN.ST.N PR.STP.1 (o PR.STP.2…PR.STP.192) STEP FOR STEP START se modali-
tà“Programmatore semplificato”disattiva; o PR.STP.1…PR.STP.16 STEP FOR
STEP START se modalità“Programmatore semplificato”attiva.
PR.STP R W
The parameter shows and sets step n of the other programmer used as consent to execute the step of the programmer
being configured.
Value n = 0 disables the function.
The parameter is present only with double setpoint programmer.
Unit of measurement: -
Options: 1...128 = Number for start step
4.8.21. EVN.R.1 - Event 1 during step ramp
Acronym Scrolling message Submenu Attributes
EVN.R.1 PR.STP.1 (o PR.STP.2…PR.STP.192) EVENT DURING STEP RAMP se moda-
lità“Programmatore semplificato”disattiva; o PR.STP.1…PR.STP.16 EVENT
DURING STEP RAMP se modalità“Programmatore semplificato”attiva.
PR.STP R W
The parameter shows and sets the configuration of event 1 during the step ramp.
Unit of measurement: -
Options: nonE = Event not modified
On = Event becomes active
OFF = Event becomes inactive
