gefran 1650 User Manual

80209C_MHW_850-1650-1850_01-2020_ITA_pag. 277
GENERAL DATA
POWER SUPPLY
Operating voltage 100...240 VAC/VDC ±10%, 50/60 Hz
(20...27 VAC/VDC ±10%, 50/60 Hz)
Power dissipation 12 W max
Protections Overvoltage 300 V / 35 V
Connection Screw terminals and crimp connector, max. wire section 1 mm
2
CONNECTIONS
Serial configuration port Connector: microUSB
RS485
(option)
Baudrate: 1200, 2400, 4800, 9600, 19.200, 38.400, 57.600, 115.200
bit/s
Protocol: Modbus RTU
Insulation compared to main entrance
Screw terminals and crimp connector, max. wire section 2.5 mm
2
Master Modbus Baudrate: 1200, 2400, 4800, 9600, 19.200, 38.400, 57.600,
115.200 bit/s
Protocol: Modbus RTU Master
Connettore RJ10
RTU Bridge Baudrate: 1200, 2400, 4800, 9600, 19.200, 38.400, 57.600,
115.200 bit/s
Protocol: Modbus RTU Master
Screw terminals and crimp connector, max. wire secti
on 2.5 mm
2
Ethernet Modbus TCP
and Webserver
(option)
Baudrate : 10/100BaseTX, 10/100Mbit/s
Protocol : Modbus TCP slave, integrated Webserver
Isolation from other peripherals
Standard RJ45 connector
Inputs and outputs Screw terminals and crimp connector, max. wire section 2.5 mm
2
AMBIENT
CONDITIONS
Use Internal
Altitude 2000 m max
Operating temperature -10 ... +55 °C (as per IEC 68-2-14)
Storage temperature -20 ... +70 °C (as per IEC 68-2-14)
Relative humidity 20...85% RH non condensante (as per IEC 68-2-3)
PROTECTION LEVEL IP 65 on front panel (as per IEC 68-2-3)
ASSEMBLY
Positioning On panel, removable faceplate
Installation regulations Installation category: II
Pollution degree: 2
Isolation: double
DIMENSIONS 96 X 96 mm (1/4 DIN)
Depth: 80 mm
WEIGHT 0,24 kg
CE STANDARDS
EMC
(electromagnetic compatibility)
Conforms to Directive 2014/30/EU norme EN 61326-1
Emissions in industrial environment classe A
LVD safety Conforms to Directive 2014/35/EU norme EN 61010-1
1) Programming is done with the GF_eXpress configuration program.

gefran 1650 Specifications

General

Brand	gefran
Model	1650
Category	Temperature Controller
Language	English
