gefran SIEIDrive ADL300 Functions Description And Parameters List

ADL300 • Functions description and parameters list 107
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.34 4630 OverV restart ENUM Disable 0 1 ERW FVS
Enabling of automatic restart after the Overvoltage alarm. This alarm indicates an overvoltage on the intermediate circuit
(DC link)
0 Disable
1 Enable
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.35 4632 OverV restart time ms UINT16 2000 1000 10000 ERW FVS
Setting of the time within which the Overvoltage alarm must be reset in order to perform automatic restart. (Time with
alarm signal active + 1000 msec).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.36 4640 UnderV restart ENUM Enable 0 1 ERW FVS
Enabling of automatic restart after the Undervoltage alarm. This alarm indicates an undervoltage on the intermediate
circuit (DC link).
0 Disable
1 Enable
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.37 4642 UnderV restart time ms UINT16 1000 120 10000 ERW FVS
Setting of the time within which the Undervoltage alarm must be reset in order to perform automatic restart. (Time with
alarm signal active + 100 msec).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.38 4650 UVRep attempts UINT16 5 0 1000 ERW FVS
Setting of the maximum number of attempts at automatic restart after the Undervoltage alarm before a Mult Undervolt-
age alarm is generated. If this parameter is set to 1000 an innite number of attempts are available.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.39 4652 UVRep delay s UINT16 240 0 300 ERW FVS
Setting of the time within which, if no automatic restarts are executed after the Undervoltage alarm, the attempts counter
is reset. In this way the number of attempts set in Underv res attempts are still available.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.40 4660 PhLoss activity ENUM Disable 0 4 ERW FVS
Setting of the behaviour of the drive in case of a PhLoss alarm. This alarm indicates the absence of a drive power supply
phase.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.41 4662 PhLoss restart ENUM Disable 0 1 ERW FVS
Enabling of automatic restart after the PhLoss alarm.
0 Disable
1 Enable
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.42 4664 PhLoss restart time ms UINT16 1000 120 10000 ERW FVS
Setting of the time within which the Phase loss alarm must be reset in order to perform automatic restart. (Time with alarm
signal active + 100 msec).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.43 4668 PhLoss output test ENUM Enable 0 2 ERWZ FVS
