ADL300 • Functions description and parameters list 23
7 The system waits for the brake to be opened (Brake open delay)
8 When the delay before opening the brake has elapsed the Start lift command is sent and movement is enabled.
Sequence of movement:
1 The motor is started and moves slowly at the speed set in Smooth start speed for the time indicated in Smooth start
delay
2 At the end of Smooth start delay, movements are managed by the multispeeds and S-shaped ramp
3 When the set speed is exceeded, the Brake 2 mon output signal can be used to check that the brake has actually been
opened
4 The EFC function with space control can be used to change to a slower speed
5 When the Start forward/reverse signal is lowered the signal indicating arrival at the oor is enabled and the start lift
signal is disabled
6 The start command can be sent again until the drive reaches zero speed: the operating conditions are restored.
Stopping sequence:
1 When zero speed is reached the DC stop command is enabled (SSC control)
2 The application waits the time needed to reach zero speed and sends the command to close brakes 1 and 2
3 It waits the time necessary for the brakes to close (Brake close delay) and, if the current is to be reduced with a ramp, it
waits for the current limit to reach zero. The internal Enable lift, arrival zone and DC brake signals are then lowered.
4 The application waits the time set in Contactor open delay and checks that the current supplied is zero, before sending
a command to open the contactors.
It is essential to make sure that whenever a drive alarm condition is generated or the drive is disabled, the drive is stopped
and a command is sent to open the contactors.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.3.1 11060 Sequence start mode ENUM 0 0 2 RW FVS
Setting of the procedure to start the contactor command sequence.
0 Start forward/reverse
1 Enable
2 Multispeed != 0
If set to 0 the contactor sequences can be enabled without the Enable command (Enable is only required for motor opera-
tion). The Enable signal can be sent by an auxiliary contact of the output contactors.
If set to 1 the contactor sequences can only be enabled if the Enable command is active.
If set to 2 the contactor sequences can be enabled using the multispeed values. Multispeed values other than 0 cause the
sequence to start. The start command must also be enabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.3.2 11062 Cont close delay ms INT32 200.00 0 10000 RW FVS
Setting of the delay time for closing the contactor.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.3.3 11064 Brake open delay ms INT32 200 0 10000 RW FVS
Setting of the brake opening delay time.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.3.4 11066 Smooth start delay ms INT32 0 0 10000 RW FVS
Setting of the time for which the Smooth start speed speed is enabled. If this parameter is set to zero, the S-shaped
prole is executed directly at the start, and the soft start function is excluded.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.3.5 11068 Brake close delay ms INT32 500.00 0 10000 RW FVS
Setting of the brake closing delay time.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.3.6 11070 Current down delay ms INT32 200 0 10000 RW FVS
