30 ADL300 • Functions description and parameters list
Landing distance
Floor level
Landing sensor
Lift car
Slow distance
Slow Down
sensor
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.5.2 11104 Distance multispeed1 m FLOAT 0.00 0.00 10.00 RW FVS
Setting of the value of the distance associated with multispeed 1.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.5.3 11106 Distance multispeed2 m FLOAT 0.00 0.00 10.00 RW FVS
Setting of the value of the distance associated with multispeed 2.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.5.4 11110 Distance multispeed3 m FLOAT 0.00 0.00 10.00 RW FVS
Setting of the value of the distance associated with multispeed 3.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.5.5 11112 Distance multispeed4 m FLOAT 0.00 0.00 10.00 RW FVS
Setting of the value of the distance associated with multispeed 4.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.5.6 11114 Distance multispeed5 m FLOAT 0.00 0.00 10.00 RW FVS
Setting of the value of the distance associated with multispeed 5.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.5.7 11116 Distance multispeed6 m FLOAT 0.00 0.00 10.00 RW FVS
Setting of the value of the distance associated with multispeed 6.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.5.8 11118 Distance multispeed7 m FLOAT 0.00 0.00 10.00 RW FVS
Setting of the value of the distance associated with multispeed 7.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.5.9 11120 Slow speed UINT16 0 0 9 RW FVS
Setting of the oor approach speed.
The Slow speed is the speed of approach to the landing zone. When the multispeed associated with the Slow speed is
selected the slow down space is checked in order to reach this speed in proximity to the landing zone.
0 Autoselect
1 Multispeed 0
2 Multispeed 1
3 Multispeed 2
4 Multispeed 3
5 Multispeed 4
6 Multispeed 5
7 Multispeed 6
