ADV100 • Quick installation guide - Specifications and connection 59

Rated speed [rpm]: rated speed of the motor; this value must reect the speed of the fully loaded motor at rated frequency. If slip is indicated on the motor data

plate, set the Rated speed parameter as follows: Rated speed = Synchronous speed - Slip (e.g. for a 4-pole motor Rated speed = 1500 - 70

= 1430).

Rated frequency [Hz]: rated frequency of the motor, as shown on the data plate.

Pole pairs: Number of motor pole pairs. The number of motor pole pairs is calculated using the plate data and the following formula:

P = 60 [s] x f [Hz] / nN [rpm]

Where: P = motor pole pairs, f = motor rated frequency (e.g. 50); nN = motor rated speed (e.g. 1450)

Rated power [kW]: Motor rated power; for a motor data plate with an HP power value, set the rated power kW = 0.736 x the motor power HP value.

Rated power factor: Leave the default rated power factor if the data are not available on the data plate.

Note! When data entry is complete the Take parameters command is executed automatically (menu 16 MOTOR DATA, PAR: 2020). The motor data entered during

the STARTUP WIZARD procedure are saved in a RAM memory to enable the drive to perform the necessary calculations.

These data are lost if the device is switched off. To save the motor data follow the procedure described in step 9.

At the end of the procedure proceed to step 3

Step 3 - Autotune of the motor

The drive carries out the motor autotune procedure (real measurement of motor parameters).

Autotune may last a few minutes.

Note ! If this operation generates an error message (example Error code 1), check the connections of the power and control circuits (see Step 1 - Connections),

check motor data settings (see Step 2 – Motor data setting) and then repeat the Autotune procedure (or, alternatively, select a different type of procedure

(Rotation or Still)

(3A)

STARTUP WIZARD

Run autotune rot ?

E=Yes Down=Next



(3B)

STARTUP WIZARD

Run autotune still ?

E=Yes Down=Next

Step 3A - Self-tuning with rotating motor (Autotune rotation)

Use this procedure when the motor is not coupled or the transmission does not represent more than 5% of the load.

This procedure obtains the most accurate data.

Note ! Autotuning can be cancelled at any time by pressing

STARTUP WIZARD

Run autotune rot

E=Yes Down=Next

STARTUP WIZARD

Close Enable input

Esc=Abort

Connect terminal 9 (Enable) to terminal 12

(+24Vdc). To interrupt this operation, press

the ESC key.

SEQ

SEQ. 01 PAR 2022

Autotune rotation

Press E to execute

Autotune

Progress: 5%

Press ESC to abort



Autotune

Done

Autotune

Open Enable input

Note ! At the end of the self-tuning procedure there is a request to open the Enable contact (terminals 7 – S3); the Take tune parameters command (menu 16 MO-

TOR DATA, PAR: 2078) is automatically executed.

The calculated parameters are saved in a RAM memory to enable the drive to perform the necessary calculations. These data are lost if the device is

switched off. To save the motor data follow the procedure described in Step 6.

When the Enable contact is opened the drive proposes Step 4 to proceed with the wizard.
