ADV100 • Quick installation guide - Specifications and connection 65
• Input and Output terminals
The default setting of the input terminals is as follows:
- Terminal 9 Digital input E Enable
- Terminal 8 Digital input 1 FR forward src, PAR 1042
- Terminal 7 Digital input 2 FR reverse src, PAR 1044
- Terminal 6 Digital input 3 Multi ref sel 0 src
- Terminal 5 Digital input 4 Multi ref sel 1 src
- Terminal 4 Digital input 5 Fault reset src
- Terminal 12 + 24V OUT I/O supply
The default conguration of the terminals dedicated to digital outputs are as follows:
- Terminal 56 Relay 1 output Drive OK (relè 1)
- Terminal 57 COM relay 1 Common relay 1
- Terminal 54 Relay 2 output Drive ready (relè 2)
- Terminal 55 COM relay 2 Common relay 2
- Terminal 52 Relay 3 output Ritardo velocità = 0
- Terminal 53 COM relay 3 Common relays 3/4
- Terminal 50 Relay 4 output Ritardo riferim = 0
- Terminal 51 COM relay 4 Power supply relays 3/4
Signals for the digital outputs can be programmed using the Digital output 1...4 src parameters (13 - DIGITAL OUT-
PUTS menu, PAR: from 1410 to 1416) using the settings in the L_DIGSEL1 selection list.
The drive also includes two analog outputs which are not factory-set. These outputs must be enabled by setting Ana-
log out 1X src (15 - ANALOG OUTPUTS menu, PAR: 1850) and Analog out 2X src parameters (PAR: 1852) with a
signal selected from selection list L_ANOUT.
The signal available on analog outputs is ± 10V.
The analog output signal can be adjusted using Analog out 1X scale (PAR: 1858) and Analog out 2X scale param-
eters (PAR:1860).
• Keypad
Use the LOC / REM key with the Enable input open (terminal 9 on terminal strip T2) to control running, to stop and re-
verse the direction of rotation of the motor using the operator keypad on the drive. Use the potentiometer or an analog
signal to control speed.
For information on how to use a digital speed reference, see the example on ADV100 Functions description and pa-
rameters list manual, chapter A.3 . The reference can have a positive or negative value, making it possible to reverse
the direction of rotation of the motor.
When the Enable input is closed, to enable motor running press START. The motor starts the acceleration ramp and
moves to the speed set in the FWD direction. With the motor running you can adjust the speed using the Dig ramp ref
1 parameter (PAR: 600) and the acceleration/deceleration ramps using Acceleration time 0 (PAR: 700) and Decelera-
tion time 0 (PAR: 702).
To change the direction of rotation press FWD/REV.
To stop the motor with the deceleration ramp, press STOP.
If the Enable contact is opened the inverter bridge is immediately disabled and the motor stops for inertia
To return to control using the terminal strip commands and analog speed reference:
1. Stop the motor
2. Open the Enable terminal
3. Press LOC / REM key.
Note ! For more customizations and any information that is not included in this initial customization guide, see the description of the parameters in this manual.
