76 ADV100 • Quick installation guide - Specifications and connection
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
4.13 576 Display backlight BIT 0 0 1 ERW FVS
4.14 578 Language select ENUM English 0 9 RWZ FVS
0 English
1 Italian
2 French
3 German
4 Spanish
5 Polish
6 Romanian
7 Russian
8 Turkish
9 Portuguese
4.15 580 Load default BIT 0 0 1 RWZ FVS
4.16 590 Save par to keypad BIT 0 0 1 RW FVS
4.17 592 Load par from keypad BIT 0 0 1 RWZ FVS
4.18 594 Keypad memory select UINT16 1 1 5 ERW FVS
4.19 596 Save to SD card BIT 0 0 1 RW FVS
4.20 598 Load from SD card BIT 0 0 1 RWZ FVS
5 - REFERENCES
5.1 600 Dig ramp ref 1 rpm INT16 16/32BIT 0 CALCI CALCI RW FVS
5.2 602 Dig ramp ref 2 rpm INT16 16/32BIT 0 CALCI CALCI ERW FVS
5.3 604 Dig ramp ref 3 rpm INT16 16/32BIT 0 CALCI CALCI ERW FVS
5.4 610 Ramp ref 1 src LINK 16/32BIT 852 0 16384 RW FVS
L�MLTREF
5.5 612 Ramp ref 2 src LINK 16/32BIT 602 0 16384 ERW FVS
L�MLTREF
5.6 614 Ramp ref 3 src LINK 16/32BIT 894 0 16384 ERW FVS
L�MLTREF
5.7 616 Ramp ref invert src LINK 16BIT 1050 0 16384 ERW FVS
L�DIGSEL2
5.8 620 Ramp ref 1 mon rpm INT16 0 0 0 R FVS
5.9 622 Ramp ref 2 mon rpm INT16 0 0 0 ER FVS
5.10 624 Ramp ref 3 mon rpm INT16 0 0 0 ER FVS
5.11 634 Ramp ref top lim rpm INT32 0 0 CALCI ERWZ FVS
5.12 636 Ramp ref bottom lim rpm INT32 0 0 CALCI ERWZ FVS
5.13 630 Reference skip set rpm INT16 0 0 CALCI ERW FVS
5.14 632 Reference skip band rpm INT16 0 0 CALCI ERW FVS
5.15 640 Dig speed ref 1 rpm INT16 16/32BIT 0 CALCI CALCI ERW FVS
5.16 642 Dig speed ref 2 rpm INT16 16/32BIT 0 CALCI CALCI ERW FVS
5.17 650 Speed ref 1 src LINK 16/32BIT 640 0 16384 ERW FVS
L�MLTREF
5.18 652 Speed ref 2 src LINK 16/32BIT 642 0 16384 ERW FVS
L�MLTREF
5.19 654 Speed ref invert src LINK 16BIT 6000 0 16384 ERWZ FVS
L�DIGSEL2
5.20 660 Speed ref 1 mon rpm INT16 0 0 0 ER FVS
5.21 662 Speed ref 2 mon rpm INT16 0 0 0 ER FVS
5.22 670 Speed ref top lim rpm INT32 CALCI 0 CALCI ERWZ FVS
5.23 672 Speed ref bottom lim rpm INT32 CALCI CALCI 0 ERWZ FVS
5.24 680 Full scale speed rpm INT16 CALCI 50 32000 RWZ FVS
6 - RAMPS
6.1 700 Acceleration time 0 s FLOAT 10.0 0.01 1000.0 RW FVS
6.2 702 Deceleration time 0 s FLOAT 10.0 0.01 1000.0 RW FVS
6.3 704 Acceleration time 1 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.4 706 Deceleration time 1 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.5 708 Acceleration time 2 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.6 710 Deceleration time 2 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.7 712 Acceleration time 3 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.8 714 Deceleration time 3 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.9 720 Ramp type ENUM Linear 0 3 ERWZ FVS
0 Linear
1 S-Shape
2 Bypass
3 Off
6.10 722 Multi ramp sel 0 src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
6.11 724 Multi ramp sel 1 src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
6.12 726 Multi ramp sel mon UINT16 0 0 3 ER FVS
6.13 730 Accel jerk time 0 s FLOAT 1.0 0.02 10.0 ERW FVS
6.14 732 Decel jerk time 0 s FLOAT 1.0 0.02 10.0 ERW FVS
6.15 734 Accel jerk time 1 s FLOAT 1.0 0.02 10.0 ERW FVS
6.16 736 Decel jerk time 1 s FLOAT 1.0 0.02 10.0 ERW FVS
6.17 738 Accel jerk time 2 s FLOAT 1.0 0.02 10.0 ERW FVS
