ADV100 • Quick installation guide - Specifications and connection 77
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
6.18 740 Decel jerk time 2 s FLOAT 1.0 0.02 10.0 ERW FVS
6.19 742 Accel jerk time 3 s FLOAT 1.0 0.02 10.0 ERW FVS
6.20 744 Decel jerk time 3 s FLOAT 1.0 0.02 10.0 ERW FVS
6.21 750 Ramp in zero src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
6.22 752 Ramp out zero src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
6.23 754 Ramp freeze src LINK 16BIT 3480 0 16384 ERW FVS
L�DIGSEL2
7 - REFERENCE
7.1 800 Multi reference 0 rpm INT16 16/32BIT 0 CALCI CALCI RW FVS
7.2 802 Multi reference 1 rpm INT16 16/32BIT 0 CALCI CALCI RW FVS
7.3 804 Multi reference 2 rpm INT16 0 CALCI CALCI RW FVS
7.4 806 Multi reference 3 rpm INT16 0 CALCI CALCI RW FVS
7.5 808 Multi reference 4 rpm INT16 0 CALCI CALCI RW FVS
7.6 810 Multi reference 5 rpm INT16 0 CALCI CALCI RW FVS
7.7 812 Multi reference 6 rpm INT16 0 CALCI CALCI RW FVS
7.8 814 Multi reference 7 rpm INT16 0 CALCI CALCI RW FVS
7.9 816 Multi reference 8 rpm INT16 0 CALCI CALCI ERW FVS
7.10 818 Multi reference 9 rpm INT16 0 CALCI CALCI ERW FVS
7.11 820 Multi reference 10 rpm INT16 0 CALCI CALCI ERW FVS
7.12 822 Multi reference 11 rpm INT16 0 CALCI CALCI ERW FVS
7.13 824 Multi reference 12 rpm INT16 0 CALCI CALCI ERW FVS
7.14 826 Multi reference 13 rpm INT16 0 CALCI CALCI ERW FVS
7.15 828 Multi reference 14 rpm INT16 0 CALCI CALCI ERW FVS
7.16 830 Multi reference 15 rpm INT16 0 CALCI CALCI ERW FVS
7.17 832 Multi ref 0 src LINK 16/32BIT 1600 0 16384 RW FVS
L�MLTREF
7.18 834 Multi ref 1 src LINK 16/32BIT 802 0 16384 RW FVS
L�MLTREF
7.19 840 Multi ref sel 0 src LINK 16BIT 1214 0 16384 RW FVS
L�DIGSEL2
7.20 842 Multi ref sel 1 src LINK 16BIT 1216 0 16384 RW FVS
L�DIGSEL2
7.21 844 Multi ref sel 2 src LINK 16BIT 6000 0 16384 RW FVS
L�DIGSEL2
7.22 846 Multi ref sel 3 src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
7.23 850 Multi ref sel mon UINT16 0 0 15 R FVS
7.24 852 Multi ref out mon rpm INT16 16/32BIT 0 0 0 R FVS
8 - MOTORPOTENTIOMETER
8.1 870 Mpot setpoint rpm INT16 16/32BIT 0 CALCI CALCI R FVS
8.2 872 Mpot acceleration s FLOAT 5.0 0.01 1000.0 RW FVS
8.3 874 Mpot deceleration s FLOAT 5.0 0.01 1000.0 RW FVS
8.4 876 Mpot top lim rpm INT16 1500 CALCI CALCI ERW FVS
8.5 878 Mpot bottom lim rpm INT16 0 CALCI CALCI ERW FVS
8.6 880 Mpot init cfg ENUM Zero 0 3 ERW FVS
0 Last Power Off
1 Zero
2 Lower Limit
3 Upper Limit
8.7 882 Mpot preset cfg ENUM None 0 11 ERW FVS
0 None
1 Input=0
2 Input=low lim
3 Input&ref=0
4 Input&ref=low
5 Output=0
6 Output=low lim
7 Output&ref=0
8 Output&ref=low
9 Input=upp lim
10 Input&ref=upp
11 Freeze input
8.8 884 Mpot up src LINK 16BIT 6000 0 16384 RW FVS
L�DIGSEL2
8.9 886 Mpot down src LINK 16BIT 6000 0 16384 RW FVS
L�DIGSEL2
8.10 888 Mpot invert src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
8.11 890 Mpot preset src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
8.12 892 Mpot mode ENUM Fine&Last val 0 3 ERW FVS
0 Ramp&Last val
