78 ADV100 • Quick installation guide - Specifications and connection
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
1 Ramp&Follow
2 Fine&Last val
3 Fine&Follow
8.13 894 Monitor uscita Mpot rpm INT16 16/32BIT 0 0 0 ER FVS
9 - JOG FUNCTION
9.1 910 Jog setpoint rpm INT16 0 CALCI CALCI RW FVS
9.2 912 Jog acceleration s FLOAT 5.0 0.01 1000.0 RW FVS
9.3 914 Jog deceleration s FLOAT 5.0 0.01 1000.0 RW FVS
9.4 916 Jog cmd + src LINK 16BIT 6000 0 16384 RW FVS
L�DIGSEL2
9.5 918 Jog cmd - src LINK 16BIT 6000 0 16384 RW FVS
L�DIGSEL2
9.6 920 Jog output mon rpm INT16 16/32BIT 0 0 0 ER FVS
10 - MONITOR FUNCTION
10.1 930 Reference 0 thr rpm INT16 30 0 CALCI RW FVS
10.2 932 Reference 0 delay ms UINT16 400 0 10000 RW FVS
10.3 940 Speed 0 thr rpm INT16 30 0 CALCI RW FVS
10.4 942 Speed 0 delay ms UINT16 400 0 10000 RW FVS
10.5 950 Speed threshold 1 rpm INT32 0 CALCI CALCI RW FVS
10.6 952 Speed threshold 2 rpm INT32 0 CALCI CALCI RW FVS
10.7 954 Speed threshold dly ms UINT16 0 0 50000 RW FVS
10.8 960 Set speed ref src LINK 16/32BIT 628 0 16384 ERW FVS
L�CMP
10.9 962 Set speed error rpm INT16 100 0 CALCI RW FVS
10.10 964 Set speed delay ms UINT16 0 0 50000 RW FVS
10.11 968 Dig set speed ref rpm INT16 16/32BIT 0 CALCI CALCI ERW FVS
10.12 970 Speed threshold 3 rpm INT32 0 0 CALCI RW FVS
10.13 972 Speed thr hysteresis rpm INT16 0 0 CALCI RW FVS
10.14 980 Current threshold perc INT16 100 0 200 RW FVS
10.15 982 Current thr hysterr perc INT16 0 0 100 RW FVS
11 - COMMANDS
11.1 1000 Commands remote sel ENUM Terminal 0 1 RWZ FVS
0 Terminal
1 Digital
11.2 1002 Commands local sel ENUM Keypad 0 1 ERWZ FVS
0 Terminal
2 Keypad
11.3 1004 Enable/disable mode ENUM Stop/FS&Spd=0 0 3 ERW FVS
0 Off
1 Stop/FS&Spd=0
2 Stop&Spd=0
3 FS&Spd=0
11.4 1006 Speed 0 disable dly ms UINT16 1000 0 10000 ERW FVS
11.5 1008 Stop key mode ENUM Inactive 0 1 ERW FVS
0 Inactive
1 EmgStop&Alarm
11.6 1010 Comando Safe Start BIT 1 0 1 ERW FVS
11.7 1012 Dig local/remote ENUM 16BIT Remote 0 1 ERW FVS
0 Local
1 Remote
11.8 1014 Local/remote src LINK 16BIT 1012 0 16384 ERW FVS
L�DIGSEL3
11.9 1016 Terminal Start src LINK 16BIT 1048 0 16384 ERW FVS
L�DIGSEL2
11.10 1018 Digital Enable src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
11.11 1020 Digital Start src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
11.12 1022 FastStop src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
11.13 1024 Enable cmd mon BIT 16BIT 0 0 1 R FVS
11.14 1026 Start cmd mon BIT 16BIT 0 0 1 R FVS
11.15 1028 FastStop cmd mon BIT 16BIT 0 0 1 R FVS
11.16 1040 FR mode ENUM Normal 0 2 ERWZ FVS
0 Normal
1 Two wire
2 Three wire
11.17 1042 FR forward src LINK 16BIT 1210 0 16384 ERW FVS
L�DIGSEL2
11.18 1044 FR reverse src LINK 16BIT 1212 0 16384 ERW FVS
L�DIGSEL2
11.19 1046 FR *stop src LINK 16BIT 6000 0 16384 ERW FVS
