80 ADV100 • Quick installation guide - Specifications and connection
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
L�DIGSEL2
14.29 1678 An inp 2X altsel src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2
14.30 1682 Analog input 2X dest ILINK 0 0 0 ER FVS
15 - ANALOG OUTPUTS
15.1 1850 Analog out 1X src LINK 16/32BIT 6000 0 16384 RW FVS
L�ANOUT
15.2 1852 Analog out 2X src LINK 16/32BIT 6000 0 16384 RW FVS
L�ANOUT
15.3 1858 Analog out 1X scale FLOAT 1.0 -10.0 10.0 RW FVS
15.4 1860 Analog out 2X scale FLOAT 1.0 -10.0 10.0 RW FVS
15.5 1866 Analog out 1X mon cnt INT16 0 0 0 ER FVS
15.6 1868 Analog out 2X mon cnt INT16 0 0 0 ER FVS
15.7 1874 An out 1X absolute ENUM Disable 0 1 ERW FVS
0 Disable
1 Enable
15.8 1876 An out 2X absolute ENUM Disable 0 1 ERW FVS
0 Disable
1 Enable
15.9 1882 Analog out 1X min cnt INT16 -16384 -32768 +32767 ERW FVS
15.10 1884 Analog out 1X max cnt INT16 16384 -32768 +32767 ERW FVS
15.11 1890 Analog out 2X min cnt INT16 -16384 -32768 +32767 ERW FVS
15.12 1892 Analog out 2X max cnt INT16 16384 -32768 +32767 ERW FVS
15.13 1898 Analog out 2X type ENUM -10V..+10V 0 2 ERW FVS
0 0..20mA
1 4..20mA
2 -10V..+10V
16 - MOTOR DATA
16.1 2000 Rated voltage V FLOAT SIZE 50.0 690.0 RWZS FVS
16.2 2002 Rated current A FLOAT SIZE 1.0 2200.0 RWZS FVS
16.3 2004 Rated speed rpm FLOAT SIZE 10.0 32000.0 RWZS FVS
16.4 2006 Rated frequency Hz FLOAT SIZE 10.0 1000.0 RWZS FVS
16.5 2008 Pole pairs UINT16 SIZE 1 20 RWZS FVS
16.6 2010 Rated power kW FLOAT SIZE 0.1 1500.0 RWZS FVS
16.7 2012 Rated power factor FLOAT SIZE 0.6 0.95 RWZS FVS
16.8 2020 Take parameters BIT 0 0 1 RWZ FVS
16.9 2022 Autotune rotation BIT 0 0 1 RWZ FVS
16.10 2024 Autotune still BIT 0 0 1 RWZ FVS
16.11 2026 Autotune mode ENUM Reduced 0 1 ERWZ FVS
0 Reduced
1 Extended
16.12 2028 Take status ENUM Required 0 0 R FVS
0 Required
1 Done
16.13 2030 Autotune status ENUM Required 0 0 R FVS
0 Required
1 Done
16.14 2050 Measured Rs ohm FLOAT CALCF 0.0005 200.0 ERWS FVS
16.15 2052 Measured DTL V FLOAT 0.0 0.0 100.0 ERWS FVS
16.16 2054 Measured DTS V/A FLOAT 0.0 0.0 100.0 ERWS FVS
16.17 2056 Measured Lsig mH FLOAT CALCF 0.1 200.0 ERWS FVS
16.18 2058 Measured ImN A FLOAT CALCF 0.1 1500.0 ERWS FVS
16.19 2060 Measured ImX A FLOAT CALCF 0.0 0.0 ERWS FVS
16.20 2062 Measured FlxN Wb FLOAT CALCF 0.05 10.0 ERWS FVS
16.21 2064 Measured FlxX Wb FLOAT CALCF 0.0 0.0 ERWS FVS
16.22 2066 Measured P1 FLOAT 0.5 0.0 1.0 ERWS FVS
16.23 2068 Measured P2 FLOAT 9.0 3.0 18.0 ERWS FVS
16.24 2070 Measured P3 FLOAT 0.87 0.0 1.0 ERWS FVS
16.25 2072 Measured Rr ohm FLOAT CALCF 0.0005 200.0 ERWS FVS
16.26 2078 Take tune parameters BIT 0 0 1 ERWZ FVS
17 - ENCODER CONFIG
17.1 2100 Encoder 1 pulses ppr UINT16 1024 128 16384 RWZ FVS
17.2 2102 Encoder 1 supply V FLOAT 5.2 5.2 CALCF ERWZ FVS
17.3 2104 Encoder 1 input cfg ENUM TTL 0 1 ERWZ FVS
0 HTL
1 TTL
17.4 2106 Encoder 1 repetition ENUM No division 0 3 ERWZ FVS
0 No division
1 Divide 2
2 Divide 4
3 Divide 8
17.5 2108 Encoder 1 signal Vpp V FLOAT 1.0 0.8 1.2 ERWZ FVS
