86 ADV100 • Quick installation guide - Specifications and connection
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
8 Eu float
9 Par16
10 Par32
23.3.27 4084 Fieldbus M->S7 mon INT32 32 BIT 0 0 0 ER FVS
23.3.28 4086 Fieldbus M->S7 div float 1.0 1.0 1000.0 ERW FVS
23.3.29 4090 Fieldbus M->S8 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.30 4092 Fieldbus M->S8 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.3.31 4094 Fieldbus M->S8 mon INT32 32 BIT 0 0 0 ER FVS
23.3.32 4096 Fieldbus M->S8 div float 1.0 1.0 1000.0 ERW FVS
23.3.33 4100 Fieldbus M->S9 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.34 4102 Fieldbus M->S9 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.3.35 4104 Fieldbus M->S9 mon INT32 32 BIT 0 0 0 ER FVS
23.3.36 4106 Fieldbus M->S9 div float 1.0 1.0 1000.0 ERW FVS
23.3.37 4110 Fieldbus M->S10 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.38 4112 Fieldbus M->S10 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.3.39 4114 Fieldbus M->S10 mon INT32 32 BIT 0 0 0 ER FVS
23.3.40 4116 Fieldbus M->S10 div float 1.0 1.0 1000.0 ERW FVS
23.3.41 4120 Fieldbus M->S11 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.42 4122 Fieldbus M->S11 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.3.43 4124 Fieldbus M->S11 mon INT32 32 BIT 0 0 0 ER FVS
23.3.44 4126 Fieldbus M->S11 div float 1.0 1.0 1000.0 ERW FVS
23.3.45 4130 Fieldbus M->S12 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.46 4132 Fieldbus M->S12 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
