ADV100 • Quick installation guide - Specifications and connection 85
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
7 EU
8 Eu float
9 Par16
10 Par32
23.3.7 4034 Fieldbus M->S2 mon INT32 32 BIT 0 0 0 ER FVS
23.3.8 4036 Fieldbus M->S2 div float 1.0 1.0 1000.0 ERW FVS
23.3.9 4040 Fieldbus M->S3 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.10 4042 Fieldbus M->S3 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.3.11 4044 Fieldbus M->S3 mon INT32 32 BIT 0 0 0 ER FVS
23.3.12 4046 Fieldbus M->S3 div float 1.0 1.0 1000.0 ERW FVS
23.3.13 4050 Fieldbus M->S4 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.14 4052 Fieldbus M->S4 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.3.15 4054 Fieldbus M->S4 mon INT32 32 BIT 0 0 0 ER FVS
23.3.16 4056 Fieldbus M->S4 div float 1.0 1.0 1000.0 ERW FVS
23.3.17 4060 Fieldbus M->S5 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.18 4062 Fieldbus M->S5 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.3.19 4064 Fieldbus M->S5 mon INT32 32 BIT 0 0 0 ER FVS
23.3.20 4066 Fieldbus M->S5 div float 1.0 1.0 1000.0 ERW FVS
23.3.21 4070 Fieldbus M->S6 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.22 4072 Fieldbus M->S6 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.3.23 4074 Fieldbus M->S6 mon INT32 32 BIT 0 0 0 ER FVS
23.3.24 4076 Fieldbus M->S6 div float 1.0 1.0 1000.0 ERW FVS
23.3.25 4080 Fieldbus M->S7 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.26 4082 Fieldbus M->S7 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
