84 ADV100 • Quick installation guide - Specifications and connection
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
23.1.1 3800 Drive address UINT16 1 1 255 ERW FVS
23.1.2 3802 Serial baudrate ENUM 38400 0 2 ERW FVS
0 9600
1 19200
2 38400
23.1.3 3810 Serial parameter ENUM None,8,1 0 3 ERW FVS
0 None,8,1
1 None,8,2
2 Even,8,1
3 Odd,8,1
23.1.4 3804 Serial protocol ENUM Modbus 0 1 ERW FVS
0 Modbus
1 Jbus
23.1.5 3806 Serial delay ms UINT16 0 0 1000 ERW FVS
23.1.6 3808 Serial swap data BIT 0 0 1 ERW FVS
23.2 - COMMUNICATION/FIELDBUS CONFIG
23.2.1 4000 Fieldbus type ENUM Off 0 3 RW FVS
0 Off
1 CanOpen
2 DeviceNet
10 DS402
23.2.2 4004 Fieldbus baudrate ENUM 500k 0 12 RW FVS
0 Auto
1 125k
2 250k
3 500k
4 1M
5 9600
6 19200
7 93750
8 187,5k
9 1,5M
10 3M
11 6M
12 12M
23.2.3 4006 Fieldbus address INT16 3 0 255 RW FVS
23.2.4 4010 Fieldbus M->S enable ENUM Enable 0 1 ERWZ FVS
0 Disable
1 Enable
23.2.5 4012 Fieldbus alarm mode INT32 0 0 1 ERWZ FVS
23.2.6 4014 Fieldbus state ENUM Stop 0 7 R FVS
0 Stop
1 PreOperational
2 Operational
3 Error
4 WaitPRM
5 WaitCFG
6 DataExchange
7 DPError
23.3 - COMMUNICATION/FIELDBUS M2S
23.3.1 4020 Fieldbus M->S1 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.2 4022 Fieldbus M->S1 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count 16
2 Count 32
3 Fill 16
4 Fill 32
5 Mdplc 16
6 Mdplc 32
7 EU
8 Eu float
9 Par 16
10 Par 32
23.3.3 4024 Fieldbus M->S1 mon INT32 32BIT 0 0 0 ER FVS
23.3.4 4026 Fieldbus M->S1 div float 1.0 1.0 1000.0 ERW FVS
23.3.5 4030 Fieldbus M->S2 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.6 4032 Fieldbus M->S2 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
