ADV100 • Quick installation guide - Specifications and connection 83
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
22.4 - FUNCTIONS/BRES OVERLOAD
22.4.1 3250 Bres control BIT 0 0 1 ERWZ FVS
22.4.2 3252 Bres value ohm FLOAT SIZE 7.0 1000.0 ERWS FVS
22.4.3 3254 Bres cont power kW FLOAT SIZE 0.1 100.0 ERWS FVS
22.4.4 3256 Bres overload factor FLOAT SIZE 1.5 10.0 ERWS FVS
22.4.5 3258 Bres overload time s FLOAT SIZE 0.5 50.0 ERWS FVS
22.5 - FUNCTIONS/SPEED CAPTURE
22.5.1 3350 Speed capture ENUM Disable 0 1 ERW FV�
0 Disable
1 Enable
22.5.2 3364 Vf catch start freq Hz FLOAT 50.0 -500.0 500.0 ERWZ �V�
22.5.3 3366 Vf catch enable dly ms UINT16 1000 10 10000 ERWZ �V�
22.5.4 3368 Vf catch search time s FLOAT 2.0 1.0 20.0 ERW �V�
22.5.5 3370 Vf catch P gain perc FLOAT 10.0 0.0 100.0 ERW �V�
22.5.6 3372 Vf catch I time ms UINT16 200 200 1000 ERW �V�
22.5.7 3376 Vf catch lastref dly ms UINT16 0 0 30000 ERWZ �V�
22.6 - FUNCTIONS/POWER LOSS
22.6.1 3400 Powerloss function ENUM Disable 0 1 ERWZ FV�
0 Disable
1 Enable
22.6.2 3402 Powerloss accel time s FLOAT 10.0 0.01 100.0 ERW FV�
22.6.3 3404 Powerloss decel times s FLOAT 2.0 0.01 100.0 ERW FV�
22.6.4 3420 Powerloss P gain A/V FLOAT CALCF 0.0 100.000 ERWS FV�
22.6.5 3422 Powerloss I time ms FLOAT CALCF 1.0 1000.0 ERWS FV�
22.6.6 3438 Powerloss mode ENUM Ramp down 0 1 ERWZ FV�
0 Ramp down
1 Restart
22.6.7 3440 Powerloss mains src LINK 16BIT 6000 0 16384 ERWZ FV�
L�DIGSEL2
22.7 - FUNCTIONS/PADS
22.7.1 3700 Pad 1 INT32 32BIT 0 0 0 ERW FVS
22.7.2 3702 Pad 2 INT32 32BIT 0 0 0 ERW FVS
22.7.3 3704 Pad 3 INT32 32BIT 0 0 0 ERW FVS
22.7.4 3706 Pad 4 INT32 32BIT 0 0 0 ERW FVS
22.7.5 3708 Pad 5 INT32 32BIT 0 0 0 ERW FVS
22.7.6 3710 Pad 6 INT32 32BIT 0 0 0 ERW FVS
22.7.7 3712 Pad 7 INT32 32BIT 0 0 0 ERW FVS
22.7.8 3714 Pad 8 INT32 32BIT 0 0 0 ERW FVS
22.7.9 3716 Pad 9 INT32 32BIT 0 0 0 ERW FVS
22.7.10 3718 Pad 10 INT32 32BIT 0 0 0 ERW FVS
22.7.11 3720 Pad 11 INT32 32BIT 0 0 0 ERW FVS
22.7.12 3722 Pad 12 INT32 32BIT 0 0 0 ERW FVS
22.7.13 3724 Pad 13 INT32 32BIT 0 0 0 ERW FVS
22.7.14 3726 Pad 14 INT32 32BIT 0 0 0 ERW FVS
22.7.15 3728 Pad 15 INT32 32BIT 0 0 0 ERW FVS
22.7.16 3730 Pad 16 INT32 32BIT 0 0 0 ERW FVS
22.8 - FUNCTIONS/VDC CONTROL
22.8.1 3450 Vdc control function ENUM Disable 0 1 ERWZ FVS
0 Disable
1 Enable
22.8.2 3470 Vdc control P gain A/V FLOAT CALCF 0.0 100.000 ERWS FVS
22.8.3 3472 Vdc control I time ms FLOAT CALCF 1.0 1000.0 ERWS FVS
22.9 - FUNCTIONS/BRAKE CONTROL
22.9.1 3170 Brake control funct ENUM Disable 0 1 ERWZ FVS
0 Disable
1 Enable
22.9.2 3172 Brake open delay s FLOAT 0.20 0.0 60.0 ERW FVS
22.9.3 3174 Brake close delay s FLOAT 0.20 0.0 60.0 ERW FVS
22.10 - FUNCTIONS/VF ENERGY SAVE
22.10.1 3320 Energysave enable BIT 0 0 1 ERWZ �V�
22.10.2 3322 Energysave spd band rpm INT16 2 0 100 ERW �V�
22.10.3 3324 Energysave delay s FLOAT 3.0 0.1 120.0 ERW �V�
22.10.4 3326 Energysave trqband 1 perc FLOAT 10.0 0.0 100.0 ERWS �V�
22.10.5 3328 Energysave trqband 2 perc FLOAT 10.0 0.0 100.0 ERWS �V�
22.10.6 3340 Energysave out FLOAT 16/32BIT 0.0 0.0 1.0 ER �V�
23 - COMMUNICATION
23.1 - COMMUNICATION /RS232
